Model Details

MEZZ-R5-4848

Printer Friendly
MEZZ-R5-4848

Steel Rotating Mezzanine Safety Gate System 53 In. x 53 In. x 42-3/16 In. 5,000 Lb. Capacity Yellow

Safety has always been the number one priority of the rotating mezzanine system. The rotational design can be maneuvered into different positions with minimal manual labor, simplifying the loading unloading process. The mezzanine system includes three gated sides and one open side, ensuring security and stability of both personnel and items. The single open mezzanine side enables pallets and boxes to be transferred safely and efficiently. An extended height, raised lip, on the three gated sides limit possible slide-offs of any small items. Unit includes a yellow and black powder coat finish for baked in added toughness.

  • Simple manual turning operation for movement of products
  • Secure access point for pallets and goods
  • Durable steel construction
  • Rotates 360 degrees
Total Ship Wt.(lbs.): 659 (only 1 package) Size: 53"W x 53"L x 42.1875"H Color: Yellow / Black

Uniform Capacity (lb.): 5000 Hardware Included: Yes Base Plate Mounting Holes: 4
Base Plate Hole Diameter (in.): 7/8 Handrail Length (in.): 51-1/2 Handrail Height (in.): 39-3/16
Midrail Height (in.): 16-7/8

Quickship Item?


NOT A Quickship Item

Can It Ship UPS/FedEx?


LTL - Must Go Truck

Image Gallery

PDF Documents

Details For Model: MEZZ-R5-4848
MEZZ-R5-4848

Steel Rotating Mezzanine Safety Gate System 53 In. x 53 In. x 42-3/16 In. 5,000 Lb. Capacity Yellow

Safety has always been the number one priority of the rotating mezzanine system. The rotational design can be maneuvered into different positions with minimal manual labor, simplifying the loading unloading process. The mezzanine system includes three gated sides and one open side, ensuring security and stability of both personnel and items. The single open mezzanine side enables pallets and boxes to be transferred safely and efficiently. An extended height, raised lip, on the three gated sides limit possible slide-offs of any small items. Unit includes a yellow and black powder coat finish for baked in added toughness.

  • Simple manual turning operation for movement of products
  • Secure access point for pallets and goods
  • Durable steel construction
  • Rotates 360 degrees
Dimensions: 53"W x 53"L x 42.1875"H Sell UOM: EA-Each Color: Yellow / Black
Material: Steel UPC: 691215363396 GTIN: 00691215363396
Warranty: -- Shipping Weight: 659 Quickship Item? --
Can It Ship UPS? -- Option? N Origin: United States
Assembly: Assembled Packaging: BASE_UNIT_OR_EACH Drawing Required? N
Uniform Capacity (lb.): 5000 Hardware Included: Yes Base Plate Mounting Holes: 4
Base Plate Hole Diameter (in.): 7/8 Handrail Length (in.): 51-1/2 Handrail Height (in.): 39-3/16
Midrail Height (in.): 16-7/8
