Model Details

ODMD-3660-10

ODMD-3660-10

Steel Open Deck Machinery Dolly 60 In. x 36 In. x 8-1/2 In. 10,000 Lb. Capacity Yellow

The open deck machinery dolly has six (6) high-capacity, abrasion-resistant, cast iron steel wheels on fixed axles to move heavy machinery, containers, and other equipment. The center wheels project lower than end wheels for easier pivoting. The dolly has a channel steel frame.

  • Heavy-duty welded steel construction provides maximum strength
  • Six cast iron wheels provide easy portability
  • Tilt mounted configured wheels allow easy turning
  • Bearing wheels provide long wheel life
Total Ship Wt.(lbs.): 328 (only 1 package) Size: 36"W x 60"L x 8.5"H Color: Yellow

Uniform Static Capacity (lb.): 10,000 Center Opening Width (in.): 21-3/16 Center Opening Length (in.): 56-3/16
Cast Iron Wheel with Roller Bearings Quantity/Diameter/Width (in.): (6) 8 x 3 Frame Channel (in.): 6

Quickship Item?


NOT A Quickship Item

Can It Ship UPS/FedEx?


LTL - Must Go Truck

Image Gallery

PDF Documents

Details For Model: ODMD-3660-10


ODMD-3660-10

Steel Open Deck Machinery Dolly 60 In. x 36 In. x 8-1/2 In. 10,000 Lb. Capacity Yellow

The open deck machinery dolly has six (6) high-capacity, abrasion-resistant, cast iron steel wheels on fixed axles to move heavy machinery, containers, and other equipment. The center wheels project lower than end wheels for easier pivoting. The dolly has a channel steel frame.

  • Heavy-duty welded steel construction provides maximum strength
  • Six cast iron wheels provide easy portability
  • Tilt mounted configured wheels allow easy turning
  • Bearing wheels provide long wheel life
Dimensions: 36"W x 60"L x 8.5"H Sell UOM: EA-Each Color: Yellow
Material: Steel UPC: 691215029049 GTIN: 00691215029049
Warranty: -- Shipping Weight: 328 Quickship Item? --
Can It Ship UPS? -- Option? N Origin: United States
Assembly: Assembled Packaging: BASE_UNIT_OR_EACH Drawing Required? N
Uniform Static Capacity (lb.): 10,000 Center Opening Width (in.): 21-3/16 Center Opening Length (in.): 56-3/16
Cast Iron Wheel with Roller Bearings Quantity/Diameter/Width (in.): (6) 8 x 3 Frame Channel (in.): 6
