P. 342
348
INDUSTRIAL/COMMERCIAL CARTS & DOLLIES
Fold-Flat Plastic Cart
Unique cart folds completely flat for storage - telescopic handle folds down and casters fold up.
Handle is adjustable to three different heights and features a cushion grip for comfort. Deck
includes non-slip rubber grips and hand holes for easy carrying. Carts roll on two (2) rigid and
two (2) swivel poly casters. Cart is constructed from plastic, steel, and aluminum components.
MODEL DECK SIZE DECK UNIFORM STATIC CASTER WEIGHT
NUMBER (W x L) HEIGHT CAPACITY SIZE (POUND)
FF-FPT-1627 16¼" x 26¾" 7¼" 300 lb. 4" x 1" 16
model
FF-FPT-1627
Heavy-Duty Plastic Platform Trucks
Heavy-Duty Plastic Platform Trucks will not rust, discolor, or warp. Maintenance free and easy to
clean. Honeycomb construction is reinforced for longer life. Extra square steel tube underneath
platform to reinforce deck strength. Units roll smoothly on 6" x 2" polyurethane casters. The four
wheel cart has two (2) rigid and two (2) swivel casters, while the 6 wheel cart has four (4) swivel
model PPT-3-62
and two (2) rigid casters. Handle height 38".
MODEL DECK SIZE UNIFORM STATIC NUMBER NUMBER WEIGHT
NUMBER (W x L) HEIGHT CAPACITY OF CASTERS OF HANDLES (POUND)
PPT-2-41 30" x 60" 7½" 2,000 lb. 4 1 148
PPT-2-42 30" x 60" 7½" 2,000 lb. 4 2 158
PPT-3-61 30" x 60" 7½" 3,000 lb. 6 1 169
model PPT-2-41 PPT-3-62 30" x 60" 7½" 3,000 lb. 6 2 172
Versatile Platform Trucks with Fold Down Handle
Transport products quickly and easily in commercial or industrial applications with our Versatile
Platform Trucks. Adjustable handle for pushing or pulling applications, folds down for storage.
model PC-60 Will not rust, chip, or dent. Unit rolls smoothly on polyurethane casters.
MODEL DECK SIZE HANDLE HEIGHT UNIFORM STATIC CASTER WEIGHT
NUMBER (W x L x H) PULLING/PUSHING CAPACITY SIZE (POUND)
5
PC-25 20½" x 31½" x 6" 32 /8" / 36½" 250 lb. 5" 24
5
PC-60 20½" x 31½" x 6" 35 /8" / 38" 600 lb. 5" 24
Hardwood Platform Trucks
Hardwood Platform Trucks are the economical solution to your material handling needs.
Constructed of nominal 1" thick hardwood, these platform trucks have a maximum capacity
of 1,600 pounds. Units roll smoothly on 6" x 2" mold-on-rubber casters, two (2) rigid and
series VHPT
two (2) swivel. Casters and removable chrome plated push handle are bolted on. Countersunk
holes allow for a smooth deck surface.
MODEL DECK SIZE DECK UNIFORM CASTER WEIGHT
NUMBER (W x L) HEIGHT CAPACITY TYPE (POUND)
HARDWOOD DECK
VHPT-2448* 24" x 48" 9¼" 1,600 lb. MOLD-ON-RUBBER 72
VHPT-2754* 27" x 54" 9¼" 1,600 lb. MOLD-ON-RUBBER 82
VHPT-3060* 30" x 60" 9¼" 1,600 lb. MOLD-ON-RUBBER 92
VHPT-3672 36" x 72" 9¼" 1,600 lb. MOLD-ON-RUBBER 158
series VHPT/S
HARDWOOD DECK WITH STEEL FRAME
VHPT/S-2448 24" x 48" 9 /8" 1,600 lb. MOLD-ON-RUBBER 159
5
VHPT/S-2754 27" x 54½" 9 /8" 1,600 lb. MOLD-ON-RUBBER 175
5
VHPT/S-3060 30½" x 60½" 9 /8" 1,600 lb. MOLD-ON-RUBBER 198
5
VHPT/S-3672 36½" x 72½" 9 /8" 1,600 lb. MOLD-ON-RUBBER 228
5
HANDLE DESIGN MAY VARY FROM WHAT IS SHOWN
(4) 8" x 2" PNEUMATIC CASTERS (CAPACITY 950 LBS.), MODEL VHPT-PNU
CASTERS MAY NOT BE
ATTACHED FOR
SHIPPING PURPOSES
