Page 355 - Vestil Catalog 112

361
Luggage Cart & Deluxe Platform Truck

These durable and attractive platform trucks are built for function and style. Great for hotels,
stores, and other commercial applications. Carpeted platform to prevent scratching of delicate
items. Units roll smoothly with poly-on-poly casters.

MODEL DECK SIZE UNIFORM STATIC OVERALL WEIGHT
NUMBER (W x L x H) CAPACITY HEIGHT (POUND)
LUG-C 25¾" x 49" x 11¼" 600 lb. 72" 159 model
DELUXE-C
3
DELUXE-C 25¾" x 49½" x 8½" 600 lb. 36 /8" 123
model LUG-C
Gas Powered Trailer Mover INDUSTRIAL/COMMERCIAL CARTS & DOLLIES
Gas Power Trailer Mover is compact in size and easy to use. They are maneuverable, making
them ideal for turning in tight spaces (not recommended for use on an incline or slope). 190cc
gasoline engine combined with a hydrostatic transmission provides variable speed control and
generous low speed torque for precise positioning. Rugged front foam filled tires with aggressive
tread pattern provide service on unpaved surfaces. Engine powered hand lever lifts and lowers
ball hitch. Three size ball hitch quickly converts to common sizes. Ball sizes; 1⅞", 2", and model PTM-GPT
5
1
2 /16". Overall size with handle up is 50½"W x 84 /16"L x 43 /2"H.
7
MODEL BALL UNIFORM PULL UNIFORM TONGUE WEIGHT
NUMBER SERVICE CAPACITY LIFT CAPACITY (POUND)
PTM-GPT 13" to 24" 12,000 lb. 1,000 lb. 817

Power Move Masters 24V DC POWERED STANDARD
Power Move Masters are compact in size and easy to use. They are highly maneuverable, model
making them ideal for turning in tight spaces (not recommended for use on an incline or PMM-3000-15
slope). DC powered for smooth, quiet operation with variable speed control for generous low
speed torque and precise positioning. Built in battery charger for quick recovery. In addition,
their ergonomic design provides stability and simple control. A variety of hitch attachments
along with other options are available, contact factory. The tire size is 18" x 9½". The
hydraulic lift is standard on models PMM-3000 and PMM-3000-15, 9" to 26". Optional
hydraulic lift option available on model PMM-1000. Three point mounting configurations
allow for adjustable service range.

UNIFORM UNIFORM
MODEL OVERALL SIZE TONGUE-WEIGHT LOAD PUSH/PULL WEIGHT model PMM-1000
NUMBER (W x L x H) FROM LIFT (LB.) MAXIMUM WEIGHT (POUND) shown with optional PMM-HYD-LIFT
PMM-1000 37½" x 53" x 37" 1,000 40,000 lb. 970
PMM-3000 36" x 78" x 43" 1,000 70,000 lb. 2120
PMM-3000-15 36" x 96" x 43" 3,000/1,000* 70,000 lb. 2260
PMM-HYD-LIFT HYDRAULIC LIFT OPTION, 9" TO 26" ADJUSTABLE 84
*3,000 lb. FRONT / 1,000 lb. TOP LIFT
Electric Powered Tuggers 24V DC POWERED model
PMM-3000
Electric Powered Tuggers are suitable to use in airports, hospitals, and wholesale and retail stores.
They can be used in a variety of applications like pulling industrial carts, hoppers, trash cans,
trailers, and tow bars. Ideal to push/pull loads without extreme stress or strain on the user's body.
The tuggers also help reduce the risk of accidents and injuries and improve handling efficiencies.
High torque 24V DC drive motor handles heavy-duty jobs. Ergonomic handle features easy to model
operate throttle with FWD/REV speeds and horn. Includes an electromagnetic disc brake with E-TUG-20
automatic dead-man feature that activates when the user releases the handle. Includes two (2) E-TUG-ADSH
12V batteries, an integral battery charger, and a battery level gauge.
MODEL OVERALL SIZE UNIFORM PULL WEIGHT
NUMBER (W x L x H) CAPACITY (POUND)
E-TUG-10 20¼" x 31¾" x 49¼" 1,000 lb. 350
E-TUG-20 26" x 32" x 50½" 2,000 lb. 387
E-TUG-30 29" x 32" x 52" 3,000 lb. 457 E-TUG-ABMH
OPTIONAL ATTACHMENTS
E-TUG-ADSH ADJUSTABLE DOUBLE SIDE HOOK 22
E-TUG-SABH SINGLE ADJUSTABLE BALL HITCH 14
E-TUG-ABMH ADJUSTABLE BALL MOUNT HITCH 12
E-TUG-MCLA SPRING LOADED MANUAL CHANNEL LIFT 22 Shown with
E-TUG-PINH PIN HITCH 14 model E-TUG-SABH
E-TUG-MM MULTI MOVER 31 E-TUG-MM
