8 Save time and reduce man-hours where there are no docks with a
LOADING DOCK EQUIPMENT Truck Scissor Dock Lift. Engineered and designed for maximum with Electric
Premium Truck Scissor Dock Lifts

safety and efficiency. The diamond plate deck is made of heavy
gauge steel for years of use. Hydraulic cylinders feature safety
Standard
velocity fuse if line breaks. It comes complete with upper travel
Toeguards
limit switch and overload relief valve. The push button control is on
a 20 foot long coil cord. Pre-wired control box includes magnetic
starter with overload relay. High visibility safety yellow removable
handrails with fixed toe boards are standard. Includes beveled
OPTIONS
toe-guards and electric toe-guards around perimeter of platform.
Standard external 6.5 HP 460V, 3-phase, 60 Hz motor can be
Shown with
located up to 8 feet away from lift (weighs 300 lb.)
Optional Aluminum Bridge
(one steel bridge standard)
MODEL PLATFORM LOWERED RAISED UNIFORM 460V 3-PHASE STD, OPTIONS ON PG. 9 B
OVERALL FRAME
WEIGHT
NUMBER (W x L) HEIGHT HEIGHT CAPACITY SIZE (W x L) (POUND)
WL-100-5-48 48" x 96" 8" 68" 5,000 lb. 41" x 93" 2856 A
WL-100-5-68 72" x 96" 8" 68" 5,000 lb. 62" x 93" 3501 A) ALUMINUM BRIDGE • WL-SATB
WL-100-5-78 84" x 96" 8" 68" 5,000 lb. 62" x 93" 3750 B) STEEL BRIDGE (add'l) • WL-SSTB
WL-100-5-88* 96" x 96" 8" 68" 5,000 lb. 86" x 93" 3996
WL-100-5-610 72" x 120" 8" 68" 5,000 lb. 62" x 118" 3867
WL-100-5-710 84" x 120" 8" 68" 5,000 lb. 62" x 118" 4071
WL-100-5-810* 96" x 120" 8" 68" 5,000 lb. 86" x 118" 4151
WL-100-6-68 72" x 96" 10" 70" 6,000 lb. 62" x 93" 3415
WL-100-6-78 84" x 96" 10" 70" 6,000 lb. 62" x 93" 3616
WL-100-6-88* 96" x 96" 10" 70" 6,000 lb. 86" x 93" 4211
WL-100-6-610 72" x 120" 10" 70" 6,000 lb. 62" x 118" 3983
WL-100-6-710 84" x 120" 10" 70" 6,000 lb. 62" x 118" 4082
WL-100-6-810* 96" x 120" 10" 70" 6,000 lb. 86" x 118" 4345 REMOVABLE HANDRAILS
AND TOEBOARDS
WL-100-8-68 72" x 96" 10" 70" 8,000 lb. 62" x 93" 4440 model WL-RHT
WL-100-8-78 84" x 96" 10" 70" 8,000 lb. 62" x 93" 4636
WL-100-8-88* 96" x 96" 10" 70" 8,000 lb. 86" x 93" 4742
WL-100-8-610 72" x 120" 10" 70" 8,000 lb. 62" x 118" 4851
WL-100-8-710 84" x 120" 10" 70" 8,000 lb. 62" x 118" 4957
WL-100-8-810* 96" x 120" 10" 70" 8,000 lb. 86" x 118" 5201
WL-100-10-68 72" x 96" 14" 72" 10,000 lb. 62" x 93" 5848
WL-100-10-78 84" x 96" 14" 72" 10,000 lb. 62" x 93" 6035
WL-100-10-88* 96" x 96" 14" 72" 10,000 lb. 86" x 93" 6221
WL-100-10-610 72" x 120" 14" 72" 10,000 lb. 62" x 118" 6081
WL-100-10-710 84" x 120" 14" 72" 10,000 lb. 62" x 118" 6268
WL-100-10-810* 96" x 120" 14" 72" 10,000 lb. 86" x 118" 6454
WL-100-10-612 72" x 144" 14" 72" 10,000 lb. 62" x 118" 6548 STOP SIGNAL SIGN
WL-100-10-712 84" x 144" 14" 72" 10,000 lb. 62" x 118" 6734 model WL-SSS
WL-100-10-812* 96" x 144" 14" 72" 10,000 lb. 86" x 118" 6920
WL-100-12-68 72" x 96" 14" 72" 12,000 lb. 62" x 93" 6431
WL-100-12-78 84" x 96" 14" 72" 12,000 lb. 62" x 93" 6617
WL-100-12-88* 96" x 96" 14" 72" 12,000 lb. 86" x 93" 6775
WL-100-12-610 72" x 120" 14" 72" 12,000 lb. 62" x 118" 6664
WL-100-12-710 84" x 120" 14" 72" 12,000 lb. 62" x 118" 6851
WL-100-12-810* 96" x 120" 14" 72" 12,000 lb. 86" x 118" 7037 CA Residents see
WL-100-12-612 72" x 144" 14" 72" 12,000 lb. 62" x 118" 7142 WARNING A, Pg. 459
WL-100-12-712 84" x 144" 14" 72" 12,000 lb. 62" x 118" 7269
WL-100-12-812* 96" x 144" 14" 72" 12,000 lb. 86" x 118" 7480
*Units 96" wide cannot ship LTL. These sizes will need to ship flat bed. COLD GALVANIZED COATING
Premium Truck Scissor Dock Lift Options ADDITIONAL HYDRAULIC LINE: Allows you to locate power unit further
away from the lift. 8 foot of hose is standard.
SPLIT ALUMINUM TRUCK BRIDGE: Ideal for government applications. Model WL-HH-(LENGTH) PER FOOT
72"W x 18"L. For 5K & 6K units. (110 lb. additional bridge)
Replacement of standard steel bridge. Model WL-SATB APPROACH RAMP FOR 8" LOWERED HEIGHT: 48" wide x 65" long.
Additional split aluminum bridge. Model WL-ADDSATB 7° ramp angle. 386 lb. Model WL-AR8-48
APPROACH RAMP FOR 8" LOWERED HEIGHT: 60" wide x 65" long.
SPLIT STEEL BRIDGE (additional): Split Steel Bridge that can be 7° ramp angle. 397 lb. Model WL-AR8
added to the opposite side of the Truck Scissor Dock Lift. 72" wide x 18"
long. (180 lb. additional bridge) Model WL-SSTB APPROACH RAMP FOR 10" LOWERED HEIGHT: 60" wide x 82"
long. 7° ramp angle. 517 lb. Model WL-AR10
REMOVABLE HANDRAILS/TOEBOARDS: Used on a Truck Scissor APPROACH RAMP FOR 14" LOWERED HEIGHT: 60" wide x 116"
Dock Lift that is mounted in a pit. This allows the platform to be flush with long. 7° ramp angle. 788 lb. Model WL-AR14
the floor for fork truck cross traffic. Please deduct 7½ (in.) from overall width
for usable width. Model WL-RHT **APPROACH RAMPS MUST BE ANCHORED TO THE FLOOR**
