12 The Trailer Lock Systems are designed for installation directly in front of the loading dock. The electric
LOADING DOCK EQUIPMENT hydraulic system captures the ICC bar on the back of semi-trailers. To ensure maximum safety the
Trailer Lock Systems
115V 1-PHASE

unit comes standard with an accumulator that allows the lock to follow the trailer up and down as it is
loaded/unloaded. A beeper and flashing light warns the operator if the lock does not engage the trailer
properly. A visual indication of the restraints status is shown at all times by the traffic light outside and
the control panel inside. It comes standard with light package, control panel, and three (3) large visual
signs. Draw pull shear strength is 22,500 pounds per foot.

WEIGHT
MODEL
NUMBER
DESCRIPTION
(POUND)
TL-100-F
TL-100-F-S
518
Electric Hydraulic, Polypropylene Light Pkg. 115V, 1 PH
TL-100-F-S-LED
518
Electric Hydraulic, Polypropylene LED Light Pkg. 115V, 1 PH
TL-200-HP-F
Hand Pump Hydraulic, Aluminum Light Package
405
TL-200-HP-F-S Electric Hydraulic, Aluminum Light Pkg. 115V, 1 PH 470
495
Hand Pump Hydraulic, Polypropylene Light Package
model TL-100-F Dock Traffic Systems
w/Aluminum Light Pkg.
Our Dock Traffic Systems feature flashing red and green lights. Prevent accidents and injuries by
providing clear communication between dock personnel and truck drivers. Built-in eyebrow type
sun visors increase light visibility.
Deluxe, model DTS-10, consists of one (1) yellow aluminum traffic light with both a green and
red lens (for outside), and an illuminated push-button control (for inside). Light measures 14"W
x 21¾"H and features an 8" hood over each lens (recommended for west and south exposure). 60
Watt. 115V AC. Four (4) procedure signs are included. Features incandescent lights.
ALUMINUM POLYPROPYLENE LED LIGHTS Economy, model DTS-5, comes with two (2) yellow polypropylene traffic lights, 6½"W x 11½"H, each
DTS-10 DTS-5 DTS-5-LED
having a green and a red lens. The light containing a toggle switch is placed inside the dock area for the
dock attendant and the other is placed outside for the truck driver. Four (4) signs are included. LED
CAUTION CAUTION CAUTION model never needs bulb replacements.
ENTER DEPART DEPART
ON ON ON
GREEN GREEN GREEN MODEL WEIGHT
LIGHT LIGHT LIGHT NUMBER DESCRIPTION POWER (POUND)
ONLY ONLY ONLY
DTS-10� Aluminum Housing, Incandescent Lights 115V, 1 Phase 30
Inside Outside Outside
DTS-5� Polypropylene Housing, Incandescent Lights 115V, 1 Phase 9
DTS-5-LED� Polypropylene Housing, LED Lights 115V, 1 Phase 8
DTS-5-LED-12DC Polypropylene Housing, LED Lights 12V DC 8
DTS-5-LED-24DC Polypropylene Housing, LED Lights 24V DC 8
DTS-5-LED-220V Polypropylene Housing LED Lights 220V, 1 Phase 8
Weather Stripping (for pit mounted dock levelers)
The dock leveler Weather Stripping keeps out pests and rodents and maintains the proper working
environment. The kit includes: two (2) precut side strips, one (1) precut foam insulator for the rear of
the pit, and installation hardware.
The Dual Vinyl has a white dual-seal that attaches to the side of dock levelers with self-tapping sheet
metal screws. The replacement vinyl slides into extruded channel that is attached with self-tapping screws.
The easy to install Brushes bolt on to the aluminum extrusion sides of the leveler. Then simply slide
DUAL VINYL brushes into aluminum extrusion channel.
series WS-DV
MODEL LENGTH MODEL LENGTH
NUMBER (PIT / STRIP) NUMBER (PIT / STRIP)
DUAL VINYL WS-5-DV� 50" / 41" REPLACEABLE VINYL WS-5-RV� 50" / 42"
62" / 54"
WS-6-RV�
62" / 53"
WS-6-DV�
WS-8-DV� 85" / 77" WS-8-RV� 85" / 78"
WS-10-DV� 110" / 101" WS-10-RV� 110" / 102"
MODEL
LENGTH
LENGTH
MODEL (PIT / STRIP) NUMBER (PIT / STRIP)
1" REPLACEABLE BRUSH WS-5-RB-1� 50" / 42" 1-1/2" REPLACEABLE BRUSH WS-5-RB-1.5� 50" / 42"
NUMBER
62" / 54"
WS-6-RB-1.5�
WS-6-RB-1�
62" / 54"
BRUSH WS-8-RB-1� 85" / 78" WS-8-RB-1.5� 85" / 78"
series WS-RB WS-10-RB-1� 110" / 102" WS-10-RB-1.5� 110" / 102"
