Page 64 - Vestil Catalog 112

70 Tilt Trucks
FACILITY MAINTENANCE FACILITIES MAINTENANCE multiple bins at a collective time. Great for high traffic areas such as: warehouses, fairs, ball

Durable plastic construction withstands extreme summer heat and allows collecting waste from
parks, schools, etc. Strong, one-piece molded polyethylene body with steel base tip support and
a balanced design to allow for simple dumping by one person. Easily portable on 2 large rubber
wheels and two swivel wheels. Tapered front makes it easier to pour materials into yet another
larger container. Rust resistant powder coated frame for strength and durability. Keep your waste
out of sight in our medium duty and easy-to-move tilt trucks. Not for use with fork trucks.
UNIFORM
VOLUME
MODEL
OVERALL SIZE
WEIGHT
NUMBER
(W x L x H)
TDT-50-LD-BLACK�
91
450 lb.
1/2
450 lb.
TDT-50-LD-BLUE�
91
28" x 62" x 35"
1/2
28" x 62" x 35"
91
TDT-50-LD-RED� CUBIC YARDS CAPACITY 28" x 62" x 35" (POUND)
1/2
450 lb.
TDT-50-LD-YELLOW� 1/2 450 lb. 28" x 62" x 35" 91
TDT-50-MD-BLACK� 1/2 850 lb. 28" x 62" x 35" 108
TDT-50-MD-BLUE� 1/2 850 lb. 28" x 62" x 35" 108
TDT-50-MD-RED� 1/2 850 lb. 28" x 62" x 35" 108
TDT-50-MD-YELLOW� 1/2 850 lb. 28" x 62" x 35" 108
TDT-50-HD-BLACK� 1/2 1,400 lb. 28" x 62" x 35" 113
TDT-50-HD-BLUE� 1/2 1,400 lb. 28" x 62" x 35" 113
TDT-50-HD-RED� 1/2 1,400 lb. 28" x 62" x 35" 113
TDT-50-HD-YELLOW� 1/2 1,400 lb. 28" x 62" x 35" 113
model TDT-50-HD-RED TDT-100-LD-BLACK� 1 850 lb. 32" x 73" x 42" 113
TDT-100-LD-BLUE� 1 850 lb. 32" x 73" x 42" 113
TDT-100-LD-RED� 1 850 lb. 32" x 73" x 42" 113
TDT-100-LD-YELLOW� 1 850 lb. 32" x 73" x 42" 113
TDT-100-MD-BLACK� 1 1,250 lb. 32" x 73" x 43" 135
TDT-100-MD-BLUE� 1 1,250 lb. 32" x 73" x 43" 135
TDT-100-MD-RED� 1 1,250 lb. 32" x 73" x 43" 135
TDT-100-MD-YELLOW� 1 1,250 lb. 32" x 73" x 43" 135
model TDT-100-HD-BLACK� 1 2,100 lb. 32" x 73" x 43" 140
TDT-50-HD-YELLOW
TDT-100-HD-BLUE� 1 2,100 lb. 32" x 73" x 43" 140
TDT-100-HD-RED� 1 2,100 lb. 32" x 73" x 43" 140
TDT-100-HD-YELLOW� 1 2,100 lb. 32" x 73" x 43" 140
Skid Steer Buckets
New Skid steer buckets provide an easy way to transfer products, both big and small. The universal
mounting system allows the unit to be utilized in conjunction with a variety of skid steers on the
market. A high strength front cutting edge resists wear and cuts through the toughest of terrain.
With a reinforced bottom plate and sides, and an all welded steel construction, this bucket will
perform at the highest levels. The back plate is designed to move liquid materials like concrete. An
anti-slip step guard is functionally placed at the top edge of the bucket for safe exiting of the skid
steer. Excellent for landscaping, farming, and residential operations.
Good for handling lightweight materials such as: dirt, mulch, snow, and sand.
model MODEL OVERALL SIZE HEAPED WEIGHT
EA-SKSB-72-LP NUMBER (W x D x H) CAPACITY (POUND)
EA-SKSB-60-LP 60" x 31 /16" x 18⅛" 13 cu. ft. 321
15
EA-SKSB-66-LP 66" x 31 /16" x 18⅛" 15 cu. ft. 336
15
EA-SKSB-68-LP 68" x 31 /16" x 18⅛" 16 cu. ft. 351
15
EA-SKSB-72-LP 72" x 31 /16" x 18⅛" 17 cu. ft. 366
15
EA-SKSB-76-LP 76" x 31 /16" x 18⅛" 18 cu. ft. 376
15
Industrial Scooter
model Get where you need to be quickly and safely with our manually powered Industrial Scooter.
SCOOT-DLX
Sturdy foot rest includes a manually operated rear brake that safely stops the Scooter at your
destination. Fixed height handle bars control front wheel maneuvering through narrow aisles and
doorways. A 25" wide x 21" long front platform holds up to 100 uniform pounds, ideal for crates,
boxes, and other small loads. Rolls on high performance smooth rolling 8" x 1¼" polyurethane
wheels. Ships knocked down.
MODEL OVERALL SIZE PLATFORM RIDER WEIGHT
NUMBER (W x L x H) SIZE (W x L) CAPACITY (POUND)
SCOOT-DLX� 27" x 61" x 40" 25" x 21" 230 lb. 72
