72 Deluxe Spring Driven Low Pressure Hose Reels
FACILITIES MAINTENANCE FACILITY MAINTENANCE TYPE A hazards and damaged hoses. For use with air and water only. Solid steel construction with heavy-duty

Keep air hoses off the floor and out of the way. Minimize labor, save storage space, protect against trip
brackets to resist hose pull. All reels have a full shaft and swivel to assure maximum product delivery.
Maximum temperature is 150° F. Maximum pressure is 300 psi / 21 bar. Includes self retracting hose.

LENGTH
OVERALL SIZE
MODEL
INSIDE HOSE
WEIGHT
DIAMETER
(W x D x H)
NUMBER
TYPE
(POUND)
OF HOSE
A
6¼" x 15" x 15"
VHR-20-44�
19
20 FOOT
1/4"
A
5½" x 12½" x 13"
VHR-35-44�
31
1/4"
35 FOOT
A
6" x 15" x 15½"
TYPE B
A
3/8"
26
25 FOOT
VHR-25-46�
A
50 FOOT
7½" x 19½" x 20"
3/8"
VHR-50-56�
43
B
8" x 9¼" x 18"
43
35 FOOT
1/2"
VHR-35-58�
B VHR-17-46� 6½" x 14¾" x 15½" 3/8" 17 FOOT 31
8¼" x 21" x 19¾"
55
50 FOOT
1/2"
VHR-50-78�
Standard Spring Driven Low Pressure Hose Reels
Keep air hoses off the floor and out of the way. Minimize labor, save storage space, protect against
trip hazards and damaged hoses. Maximum pressure is 300 psi / 20 bar. Includes self retracting hose.
Model SHR-P-38-50 is constructed of durable, high quality impact resistant polypropylene. A
model positive latching mechanism automatically locks hose at a desired length. A safety lock prevents the
SHR-P-38-50 hose from moving in either direction. An integral wall/overhead swivel bracket and 36" lead hose are
included. Maximum temperature is 140° F.
MODEL OVERALL SIZE INSIDE HOSE LENGTH WEIGHT
NUMBER DESCRIPTION (W x D x H) DIAMETER OF HOSE (POUND)
SHR-P-38-50� PLASTIC 8¾" x 17½" x 17¼" 3 /8" 50 FOOT 23
Air Hose Reel
Help eliminate twists and tangles of hoses, save storage space, protect against trip hazards and
damaged hoses with Air Hose Reels. This arm style reel is constructed of all steel. Quick and simple
manual hand crank and spring loaded axle helps reel in up to 100 feet of 3/8" hose or 50 feet of
1/2" hose. Valve assembly is rated at 100 psi and 25 cfm. Unit can be mounted both vertically or
horizontally. The wall bracket measures 7"W x 3"H. Hose is not included.
model MODEL OVERALL SIZE USABLE WEIGHT
REEL-16L NUMBER DESCRIPTION (W x D x H) SPACE (POUND)
REEL-16L� ARM STYLE 14" x 17¾" x 18" 5" 14
Electric Cord Reels 115V 1-PHASE STANDARD
Help eliminate the danger of tangled electrical cords with these Electric Cord Reels. The compact design
is spring retractable and engineered for industrial use. Complete with 4 foot pigtail and three prong
plug. 115V, 60 Hz single phase. Ideal for indoor non-weather tight applications only. UL listed and CSA
certified.
model Model ECR-45-S comes with a 15 AMP 3 wire single receptacle with clamp type strain relief.
ECR-45-S Model ECR-45-D features a duplex outlet box and ground fault circuit interrupter.
Comes with a 20 AMP 3 wire double receptacle.
Model ECR-50 has an incandescent lamp and single receptacle. Head has tool tap, push through
winch and metal grounded guard. 75 watt bulb maximum. Bulb not included.
MODEL WEIGHT
model NUMBER DESCRIPTION CORD LENGTH WIRE GAUGE (POUND)
ECR-45-D ECR-45-S SINGLE RECEPTACLE 45 FEET 12 24
ECR-45-D DOUBLE RECEPTACLE 45 FEET 12 31
ECR-50 LAMP WITH RECEPTACLE 50 FEET 16 25
model
ECR-50
