Product Family Overview


Rubber (DK - Conductive) Casters
SERIES: CST-F-CR

Constructed of high-grade thermoplastic rubber (tpr). Chemically bonded to core. protects against electrostatic build-up and discharge that can be generated by transport. ideal for electronic companies, medical engineering, and other environments where static build up is a concern. gray tread color. 65 shore a. wheel core is constructed of polyolefin.

  • Ohmic Resistance 10^3(omega) Exceed The Requirements Of Federal Standard Ff-c-88c
  • Non-marking
  • Smooth ride performance
  • Quiet operation
  • Exceptional floor preservation
  • Resists mosts solvents, oils, grease, wnd water
  • Premium rrecision ball bearings

Constructed of high-grade thermoplastic rubber (tpr). Chemically bonded to core. protects against electrostatic build-up and discharge that can be generated by transport. ideal for electronic companies, medical engineering, and other environments where static build up is a concern. gray tread color. 65 shore a. wheel core is constructed of polyolefin.

  • Ohmic Resistance 10^3(omega) Exceed The Requirements Of Federal Standard Ff-c-88c
  • Non-marking
  • Smooth ride performance
  • Quiet operation
  • Exceptional floor preservation
  • Resists mosts solvents, oils, grease, wnd water
  • Premium rrecision ball bearings

Model Specific Details




All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.
The Search Box below is for Casters within the Model Chart on this page. Not an entire site search.
Model Image PDFs Caster
Size
Type Capacity
(lbs.)
Overall
Height
Top Plate
Size
Net Wt.
(lbs)
CST-F-4X2CR-R 1 YEAR Limited Warranty4 x 2RIGID4505-1/2 4 x 4-1/22.83
CST-F-5X2CR-R 1 YEAR Limited Warranty5 x 2RIGID5006-1/2 4 x 4-1/23.18
CST-F-6X2CR-R 1 YEAR Limited Warranty6 x 2RIGID6007-1/2 4 x 4-1/23.66
CST-F-8X2CR-R 1 YEAR Limited Warranty8 x 2RIGID6759-1/2 4 x 4-1/24.46
CST-F-4X2CR-S 1 YEAR Limited Warranty4 x 2SWIVEL4505-1/2 4 x 4-1/23.58
CST-F-5X1TPR-S CST-F-5X1TPR-S1 Year Limited Warranty5" x 1-1/4"Swivel3256.125 4-1/8" x 3-1/8"2.2
CST-F-5X2CR-S 1 YEAR Limited Warranty5 x 2SWIVEL5006-1/2 4 x 4-1/23.95
CST-F-6X2CR-S 1 YEAR Limited Warranty6 x 2SWIVEL6007-1/2 4 x 4-1/24.43
CST-F-8X2CR-S 1 YEAR Limited Warranty8 x 2SWIVEL6759-1/2 4 x 4-1/25.27
CST-F-4X2CR-SWB CST-F-4X2CR-SWB1 YEAR Limited Warranty4 x 2SWIVEL W/BRAKE4505-1/2 4 x 4-1/23.93
CST-F-5X2CR-SWB 1 YEAR Limited Warranty5 x 2SWIVEL W/BRAKE5006-1/2 4 x 4-1/24.2
CST-F-6X2CR-SWB 1 YEAR Limited Warranty6 x 2SWIVEL W/BRAKE6007-1/2 4 x 4-1/24.83
CST-F-8X2CR-SWB 1 YEAR Limited Warranty8 x 2SWIVEL W/BRAKE6759-1/2 4 x 4-1/25.72
CST-F-4X2CR-SWTB1 1 YEAR Limited Warranty4 x 2Swivel w/Total Brake4505-1/2 4 x 4-1/24.095
CST-F-6X2CR-SWTB1 1 YEAR Limited Warranty6 x 2Swivel w/Total Brake6007-1/2 4 x 4-1/25
CST-F-8X2CR-SWTB1 1 YEAR Limited Warranty8 x 2Swivel w/Total Brake6759-1/2 4 x 4-1/25.9
CST-F-5X2CR-SWTB1 1 YEAR Limited Warranty5 x 2SWTB15006-1/2 4 x 4-1/24.5

KEY: = Click For Expanded Model Details -- = Approval Drawing -- = Testing Certificate -- Warranty


Rubber (DK - Conductive) Casters PDF's will open in a new window when clicked.

Manuals

No Owners Manuals For This Product


Survey Sheets

No Survey Sheets For This Product


Approval Drawings

No Approval Drawings For This Product

Testing Certificates


CST-F-5X2CR-SWB

CST-F-5X2CR-SWTB1

CST-F-6X2CR-SWTB1

CST-F-8X2CR-SWTB1

SDS Sheets

No SDS Sheets For This Product

Other PDF's


Directory Links Of Available PDF's For All Products

Before placing an order, please confirm that the ship to company is able to receive shipments on the estimated delivery date





Rubber (DK - Conductive) Casters




Constructed of high-grade thermoplastic rubber (tpr). Chemically bonded to core. protects against electrostatic build-up and discharge that can be generated by transport. ideal for electronic companies, medical engineering, and other environments where static build up is a concern. gray tread color. 65 shore a. wheel core is constructed of polyolefin.

  • Ohmic Resistance 10^3(omega) Exceed The Requirements Of Federal Standard Ff-c-88c
  • Non-marking
  • Smooth ride performance
  • Quiet operation
  • Exceptional floor preservation
  • Resists mosts solvents, oils, grease, wnd water
  • Premium rrecision ball bearings


No Model Numbers Associated To This Product Page
Model # Description Attributes Net Wt.
(lbs)
