DRUM HANDLING EQUIPMENT & SPECIALTY CONTAINERS
Self-Venting Drum Pumps

Designed for dispensing and transferring liquids out of 55 gallon drums, 5 gallon and 15 gallon pails.
Constructed of polypropylene for application specific chemical resistance.
VDP & VDPX - Exceptional resistance to corrosive chemicals (non-flammable solvents). VDP
includes a 2 piece dip tube with connector 32" long total.

MODEL DISPLACEMENT BUNG WEIGHT
NUMBER CONSTRUCTION PER STROKE SIZE (POUND)
model VDPX model VDP VDP POLYPROPYLENE 8 oz. ¾" & 2" 2
VDPX POLYPROPYLENE 16 oz. ¾" & 2" 2

Rotary Drum Pumps

For dispensing and transferring liquids out of 55 gallon drums.
RDP-55 - Ideal for light oils, anti-freeze, and other light non-flammable and non-combustible
liquids. Hose included.
ADP-55 - High-speed drum pump for light oils up to 40 weight. Hose included.
model RDP-55 model ADP-55
RP-90RT - Ideal for soluble, corrosive, volatile, and aggressive chemicals. Suitable for use with
Acetone, Ad-Blue and MEK.
RP-90R - For transferring soluble, corrosive, volatile, and aggressive chemicals (esters, alcohols,
alkali, acids, hydrocarbons, petroleum based fluid, transmission fluid, and water based chemicals).
RP-90FG - Suitable for most soluble, corrosive, volatile, and liquids which are compatible with
PTFE and HFP/TFE.
model RP-90RT model RP-90R
MODEL DISPLACEMENT BUNG WEIGHT
NUMBER CONSTRUCTION PER STROKE SIZE (POUND)
RDP-55 STEEL 11.8 oz. 2" 12
ADP-55 ALUMINUM 11.8 oz. 2" 14
RP-90RT PPS 11.8 oz. 2" 5
RP-90R PPS 11.8 oz. 2" 5
RP-90FG PTFE 10.14 oz. 2" 5
model RP-90FG

Lever Action Drum Pumps
model VLDP
Designed for dispensing and transferring liquids out of 55 gallon drums.
VLDP - Handles viscous liquids up to 12,000 cPs (equivalent to SAE 90 oil). Not for use above
125°F or with heated drums. Includes 35" long dip tube.
LDP-ST - For petroleum products up to 200 cPs.
model model
LDP-POLY LDP-RYT
LDP-SS-316 - Model is hand pumped rather than levered.

MODEL DISPLACEMENT BUNG WEIGHT
NUMBER CONSTRUCTION PER STROKE SIZE (POUND)
VLDP POLYPROPYLENE 10 oz. 2" 2
LDP-ST STEEL 12 oz. 2" 5
LDP-POLY POLYPROPYLENE, PLATED STEEL ROD 12 oz. 2" 4
LDP-RYT PPS, 316 SS ROD 12 oz. 2" 4
LDP-POLY-304 POLYPROPYLENE, 304 SS ROD 12 oz. 2" 4
LDP-FG PTFE, SS PISTON ROD 12 oz. 2" 4
model model LDP-SS-316 316 STAINLESS STEEL 16 oz. 2" 5
LDP-ST LDP-SS-316
