          Electric Drum Pumps        115V 1-PHASE STANDARD

          Reduce time required to dispense or transfer liquids. Electric drum pumps allow you
          to move fluid easily and efficiently.  Pumps come complete with tube for 2" bung,
          hose, and 115V motor.
          FHL-PUMP for Flammables & Hazardous Locations
          ME I 6 EX motor, Class I Group C&D, Class II Groups F&G (Explosion Proof) with
          16 ft. cord, pump tube SS 39" sealless, high volume rotor, 1" SS barrel adaptor, 1" SS
          nozzle with swivel, 8' conductive chemical tubing with conductive fittings, ground &
          bonding wires, wall hanger.                                       model EDP                model FHL-PUMP
          ODF-PUMP for Thin-Bodied Oils & Diesel Fuel
          B36 motor with 16 ft. cord, pump tube ALU 39" sealless, high head impeller, 316
          stainless steel shaft, PP Barrel Adaptor, 1" aluminum nozzle with swivel, 8" PVC hose,
          hose clamps, and wall hanger.
          ABS-PUMP for Acids & Base Solutions                                                                      DRUM HANDLING EQUIPMENT & SPECIALTY CONTAINERS
          B36 motor with 16 ft cord, pump tube PP 39" sealless, high volume rotor, Hastelloy
          C shaft, PP barrel adaptor, 3/4" PP nozzle, 8' PVC hose, hose clamps, and wall hanger.
          HCB-PUMP for Highly Corrosive Acids & Base Solutions
          B55T-5 motor with 16 ft. cord, pump tube PVDF 39" sealless, high volume rotor,
          Hastelloy C shaft, PP barrel adaptor, 1" PVDF nozzle with swivel, 8' chemical hose,   model ODF-PUMP  model ABS-PUMP
          hose clamps, and wall hanger.

             MODEL     MAXIMUM   MAXIMUM   MAXIMUM   MAXIMUM   IMMERSION  WEIGHT                    model HCB-PUMP
             NUMBER    VISCOSITY  CAPACITY   HEAD      S.G.     DEPTH    (POUND)
           EDP        400 CPS  22.75 GPM   43 FT.     1.3       39"       20
           FHL-PUMP    500 CPS  18.5 GPM    33 FT.     1.3       12"       21
           ODF-PUMP    500 CPS  15.9 GPM    68 FT.     1.4       12"       21
           ABS-PUMP    600 CPS  13.5 GPM    31 FT.     1.4       12"       18
           HCB-PUMP    500 CPS  13.5 GPM    26 FT.     1.6       39"       35


          Fire Extinguisher Carrier

          The Fire Extinguisher Carrier is designed for easily transporting your fire extinguisher up to 8" in
          diameter. Includes two (2) heavy duty adjustable rubber straps. Sturdy handle with rubber grip and
          poly casters for tilt-n-go portability. Welded steel construction with yellow baked-in powder-coat
          toughness.  4" x 2" stabilizing plate keeps unit upright when empty and helps retain extinguisher.
          Adjustable EPDM restraining straps keep extinguisher secure and allow for quick access. Wall mount
          bracket included to store the extinguisher off the floor.

              MODEL        OVERALL SIZE        WHEEL           WHEEL      WEIGHT
             NUMBER         (W x L x H)        TYPE            SIZE      (POUND)
                               1
                         3
                                    3
           FEC-1       14 /8" x 11 /8" x 41 /8"  POLY-ON-POLY  4" x 1¼"   13
                                                                                                 model FEC-1
          Wall Mounted Cylinder Brackets
          Simple design is easy to install. Simply bolt to wall and then secure cylinder with strap. Edges are
          protected with rubber guards on the steel units. Choose either steel or molded plastic construction.
          Maximum 12" cylinder diameter. Installation hardware is not included.







             model CB-W-S           model CB-W-2S           model CB-W-P                          model CB-W-3S


              MODEL                                   ACCOMMODATES       WEIGHT
             NUMBER            MATERIAL                 CYLINDERS        (POUND)
           CB-W-S              STEEL                      1               2
           CB-W-2S             STEEL                      2               7
           CB-W-3S             STEEL                      3               10
           CB-W-P             PLASTIC                     1               1
           CB-W-2P            PLASTIC                     2               2                model CB-W-2P
