226 Hand Winches
GANTRY AND JIB CRANES WARNING A, Pg. 459 WALL-S loads. Constructed of steel worm gear drives with zinc plated finish. Pinion gear shaft with lubricated

Wall Mounted Hand Winches Pulling devices that use a wire, rope, cable, strap or web to move heavy
CA Residents see
down bushings provide smooth operation and long life.
model
Stainless Steel Hand Winches are constructed of 304 stainless steel for corrosion resistance. Machine-
cut spur gears ensure smooth accurate operation, while protective gear covers keep dirt out and
help prevent worker injuries. Winches feature a drum clamp for easy attachment of wire rope (not
included), and an automatic brake for positive load control during lifting and lowering operations.

UNIFORM
GEAR
WEIGHT
MODEL
LENGTH
NUMBER
CAPACITY
TYPE
model WALL-D
5
41:1
9 /8"
SINGLE
12
WALL-S�
5
WALL-D�
13
41:1
6 /8"
1,500 lb.
STAINLESS STEEL DOUBLE 1,500 lb. RATIO HANDLE (POUND)
HWSS-1200-NR� SINGLE 1,200 lb. 4.2:1 8¼" 9
HWSS-1800-NR� SINGLE 1,800 lb. 5:1 12½" 18
model HWSS-2600-NR� SINGLE 2,600 lb. 10:1 12½" 24
HWSS-1800-NR
Manual and Worm Gear Hand Winches
Manual Hand-Operated Gear Drive Winch, model HWG-600, is designed for many lifting,
lowering, and pulling applications. Equipped with a load pressure brake. This brake holds the
load at any required height during hoisting and lowering and prevents any unintentional lowering
of the load. Adjustable crank handle for fast lifting of smaller loads, resulting in lowest possible
model HWG-600
handle effort and rapid winding of the rope. All rotating parts are maintenance-free. Suitable for
operation in ambient temperatures of 14° through 120°F. Capacity 600 pounds.
Worm Gear Hand Winch, model HWV-1000, allows for better load control and features a
reinforced frame comfort-grip handle. Worm gear provides load holding capability when handle
is released. Reel stops automatically, locking load in place whenever the handle is released. High
quality enamel paint finish, dipped and baked. Crank handle can be adjusted in length. Winch
housing and rope drum are made from robust steel plate. Capacity 1,000 pounds.
MODEL WIRE DRUM OVERALL SIZE WEIGHT
NUMBER GEAR TYPE ROPE CAPACITY (FT.) (L x W x H) (POUND)
7
7
HWG-600� MANUAL 3/16" 65 9½" x 7 /8" x 7 /8" 36
model HWV-1000 HWV-1000� WORM 1/4" 45 7" x 10¼" x 7" 35
CABLE IS NOT INCLUDED
Galvanized Two-Speed Cable Puller
Great for use in horizontal pulling applications such as positioning equipment, stringing lines,
and emergencies. Can be used in both single and double-line pulling applications. Handle
ratchets to take up cable. When handle is rotated all the way back, the cable reel will free-spool.
Handle length is 30". Minimum headroom is 24". Single-line cable length is ¼" x 120" (cable
length is 60" when used as a double-line). Not for use in vertical lifting applications.
GALVANIZED TWO-SPEED MODEL SINGLE-LINE DOUBLE-LINE SINGLE-LINE WEIGHT
CABLE PULLER
model CABLE-P4 NUMBER UNIFORM CAPACITY UNIFORM CAPACITY CABLE LENGTH (POUND)
CABLE-P4� 2,000 lb. 4,000 lb. ¼" x 120" 14
CA Residents see
WARNING A, Pg. 459
Long Reach Cable Pullers

Cable Pullers are ideal for applications requiring pulling over long distances. Pull up to 60'
without unhooking and resetting as required when using conventional lever or hand chain hoists.
Works great for pulling horizontally. Not for use in vertical lifting applications.

MODEL UNIFORM USABLE CABLE LENGTH IN CABLE DIAMETER WEIGHT
NUMBER CAPACITY FEET (~m) (APPROXIMATE) (POUND)
CP-15� 1,500 lb. 60 5 /16" 36
model CP-30 CP-30� 3,000 lb. 60 7 /16" 64
*MEETS CSIR FOR USE IN MINING INDUSTRY
