254 Crowd Control Interlocking Barriers
PROTECTIVE BARRIERS model PRAIL-102-G-WF Attractive and functional design ideal for directing personnel. Interlocking portable railing has

many commercial and industrial applications. Easy to move to meet changing needs. Upright
bars are vertically spaced at 5⅞" intervals for the light-weight style barriers and 5¾" for the heavy-
duty style. Each railing includes connectors to attach multiple units together to form long runs.
Overall size is 102"L x 40"H. Feet are removable so railing will lay flat for shipping and storage.
Variety of foot styles available. Rugged welded steel construction.
CA Residents see
WARNING A, Pg. 459
FOOT
WEIGHT
RAIL
MODEL
STYLE
STYLE
NUMBER
GALVANIZED FINISH
85
1¼"
PRAIL-102-G�
PRAIL-102-G-WW� LIGHT-WEIGHT DIAMETER BOTH CURVED (POUND)
LIGHT-WEIGHT
85
BOTH WHEELS
1¼"
PRAIL-102-G-FF� LIGHT-WEIGHT 1¼" BOTH FLAT 85
PRAIL-102-G-WF� LIGHT-WEIGHT 1¼" (1) WHEEL, (1) FLAT 85
PRAIL-102-G-W� LIGHT-WEIGHT 1¼" (1) WHEEL, (1) CURVED 85
5
PRAIL-102-HD-G� HEAVY-DUTY 1 /8" BOTH CURVED 105
PRAIL-102-HD-G-WW� HEAVY-DUTY 1 /8" BOTH WHEELS 105
5
5
PRAIL-102-HD-G-FF� HEAVY-DUTY 1 /8" BOTH FLAT 105
model PRAIL-102-HD-Y
5
PRAIL-102-HD-G-WF� HEAVY-DUTY 1 /8" (1) WHEEL, (1) FLAT 105
5
PRAIL-102-HD-G-W� HEAVY-DUTY 1 /8" (1) WHEEL, (1) CURVED 105
POWDER COAT SAFETY YELLOW FINISH
PRAIL-102-Y� LIGHT-WEIGHT 1¼" BOTH CURVED 85
PRAIL-102-Y-WW� LIGHT-WEIGHT 1¼" BOTH WHEELS 85
PRAIL-102-Y-FF� LIGHT-WEIGHT 1¼" BOTH FLAT 85
PRAIL-102-Y-WF� LIGHT-WEIGHT 1¼" (1) WHEEL, (1) FLAT 85
PRAIL-102-Y-W� LIGHT-WEIGHT 1¼" (1) WHEEL, (1) CURVED 85
5
PRAIL-102-HD-Y� HEAVY-DUTY 1 /8" BOTH CURVED 105
PRAIL-102-HD-Y-WW� HEAVY-DUTY 1 /8" BOTH WHEELS 105
5
5
CURVED FEET FLAT FEET WHEELS PRAIL-102-HD-Y-FF� HEAVY-DUTY 1 /8" BOTH FLAT 105
5
PRAIL-102-HD-Y-WF� HEAVY-DUTY 1 /8" (1) WHEEL, (1) FLAT 105
5
PRAIL-102-HD-Y-W� HEAVY-DUTY 1 /8" (1) WHEEL, (1) CURVED 105
STAINLESS STEEL TYPE 304 FINISH
PRAIL-102-SS� LIGHT-WEIGHT 1¼" BOTH CURVED 85
5
PRAIL-102-HD-SS� HEAVY-DUTY 1 /8" BOTH CURVED 105
Crowd Control Barriers Cart
A railing cart is a great addition to entertainment and recreational facilities. Designed with upper
and lower arms to enable the rails to be transported with efficiency and minimal personnel. An
extended towing arm is placed at the front of the unit for push/pull maneuvering. The unit rolls
smoothly on casters while traversing locations. Built in fork pockets 7 /16"W x 2 /2"H usable on
13
1
32 /16" centers allow the unit to be transferred and maneuvered with the use of the fork truck.
13
model PRAIL-CT-1
MODEL OVERALL SIZE USABLE SIZE CAPACITY WEIGHT
NUMBER (W x H) (W x H) (POUND) (POUND)
PRAIL-CT-1 52½" x 89¾" 48½" x 77 /16" 3,500 264
13
Plastic Barriers
Portable Barriers with removable base feet. Manufactured from virgin HDPE material and includes
UV stabilizers for longer life. Reflective tape provides better identification at night. The black recycled
rubber base feet are 23" long and are weighted for stability.
model PBAR-72-Y
MODEL WEIGHT
NUMBER LENGTH HEIGHT COLOR (POUND)
PBAR-72-Y� 79" 40" YELLOW 69
PBAR-72-O� 79" 40" ORANGE 69
model PBAR-72-O
PBAR-72-W� 79" 40" WHITE 69
Plastic Interlocking Barriers
model PBAR-72-W
Plastic Interlocking Barriers will not rust and will retain attractive appearance. Reflective tape
provides better identification at night. Barrier ends include connectors for interlocking multiple
units. Base feet are 15½"L x 3"W. The non-removable feet come pre-filled with sand for weight
ballast. Feet can be rotated 90° to allow for barriers to be stacked. Manufactured from HDPE
material and includes UV stabilizer for longer life. Ships and stores assembled.
model PHR-R MODEL OVERALL SIZE BARRIER WEIGHT
NUMBER (L x H) THICKNESS COLOR (POUND)
PHR-Y� 59" x 40" 2½" YELLOW 52
PHR-Y-L 79" x 40" 2½" YELLOW 58
PHR-R 59" x 40" 2½" RED 52
PHR-R-L 79" x 40" 2½" RED 58
model PHR-W PHR-W� 64" x 40" 2½" WHITE 56
