Steel Pick-Up/Van Ramps

These economical serrated ramps provide minimum slippage. Overlapping lip provides smooth
transition into cargo area. Single piece construction with bolt-on lip.
MODEL WIDTH GROSS SINGLE WHEEL WEIGHT
NUMBER LENGTH PER RAMP UNIFORM CAPACITY UNIFORM CAPACITY (POUND)
RAMP-72 72" 9" 1,000 lb. 500 lb. 43 pr.
RAMP-96 96" 9" 1,000 lb. 500 lb. 60 pr. model RAMP-72 LOADING DOCK EQUIPMENT
Wooden Ramp Kits

Kits allow for building wooden ramps using common lumber. Each kit includes two (2) steel end
plates and rubber bottom tips. Installation hardware is included. Drilling required for installation.
Lumber/boards are not included.
MODEL USABLE WEIGHT model RK-8
NUMBER DESCRIPTION LUMBER SIZE (POUND)
RK-8 WOODEN RAMP KIT 8" x 2" 10
RK-12 WOODEN RAMP KIT 12" x 2" 16
Steel Container Ramps with Flip-Over Bridge
Heavy duty steel container ramps facilitate easy loading/unloading of shipping containers when
placed on ground level. Hinged flip-over bridge allows for easy transportation and compact storage.
Tapered lip provides smooth transition into container at various heights. Built-in fork pockets in
base for convenient fork truck positioning.
MODEL OVERALL OVERALL UNIFORM WEIGHT
NUMBER WIDTH LENGTH HEIGHT CAPACITY (POUND) series SCR
SCR-72 76½" 98 /8" 4 /4" 15,000 lb. 816
1
1
SCR-84 88½" 98 /8" 4 /4" 15,000 lb. 924
1
1
Steel Container Ramps with Side Rails
A CRS container ramp is the perfect asset for loading and unloading products over uneven surfaces.
The steel construction is long lasting and durable throughout harsh working conditions and
inclement weather. The raised tread plate platform surface enables the user to have sure footing and
minimize worker injury during use. The beveled edges on both ends allow smooth entry/exit by
limiting the surface of height difference during transition. Side curbs also play a large role in the
user safety by helping to maintain a safe alignment of goods as they pass from one area to another.
Pick-up chains are included for simple transference of unit to different areas around the workplace.
A range of large capacity designs are available to best suit your specific needs. series CRS
MODEL RAMP SIZE WEIGHT
NUMBER DESCRIPTION (W x L) CAPACITY (POUND)
CRS-6060-15 STEEL CONTAINER RAMP 60" x 60" 15,000 lb. 448
CRS-6060-20 STEEL CONTAINER RAMP 60" x 60" 20,000 lb. 458
CRS-7272-20 STEEL CONTAINER RAMP 72" x 72" 20,000 lb. 787
CRS-8472-20 STEEL CONTAINER RAMP 84" x 72" 20,000 lb. 797
Wheel Chair Ramps

The Americans with Disabilities Act requires that all buildings must be accessible to disabled persons. Failure to comply may result in monetary
damages and civil penalties. According to ADA rules and regulations, for every inch of rise you must have a foot of ramp in length.

A) TELESCOPIC RAMP is constructed of lightweight B) FOLD-A-WAY RAMP easy, one person storage and C) GRATE RAMP is a semi-permanent ramp
aluminum extrusion. Top surface is serrated for handling. Slip-resistant surface provides extra traction. that is ideal for high traffic areas. Handrails
positive traction. Each ramp comes with 2 handles for easy positioning. are available.
MODEL DIMENSIONS UNIFORM WEIGHT
TYPE NUMBER (WIDTH x LENGTH) CAPACITY (POUND)
9
1
A D-TR-72 9 /16" x 76 /16" 550 lb. 38 pr.
1
9
A D-TR-88 9 /16" x 88 /16" 550 lb. 44 pr.
1
B D-FAR-120 12 /16" x 124" 550 lb. 78 pr.
C D-AW-88 36" x 88" 500 lb. 182 D) ROLL-O-RAMP provides access over curbs.
C D-AW-132 36" x 132" 500 lb. 177 Wheels installed on curb of ramp for
C D-AW-168 36" x 168" 500 lb. 227 portability. Beveled edges create smooth
D D-ROL-48 50 /16" x 48" 500 lb. 52 transition between ramp and ground.
7
