Stackable Drum Racks

Steel Drum Racks accommodate 55 gallon drums and feature four-way fork truck access.
Not recommended for stacking more than four (4) racks high. All steel construction with ¼" model
DRUM-RACK-3
formed steel cradles. Bolt together assembly with hardware included. Yellow painted finish. (two units shown)
Models with suffix -SS are stainless steel. Models with suffix -G are galvanized. Drums, drum
racks, and drum carts all sold separately.
Models DR-CART-2 & DR-CART-3 Portable Drum Dollies accommodate one drum rack
and feature two (2) 8" swivel casters and two (2) 8" swivel casters with wheel brake.
Models DR-CART-2-HLK & DR-CART-3-HLK Portable Drum Carts feature removable
push handle and two (2) 8" swivel casters and two (2) 8" swivel casters with wheel brake.
model DR-CART-2
MODEL DRUM OVERALL SIZE UNIFORM WEIGHT
NUMBER CAPACITY (W x D x H) CAPACITY (POUND) CA Residents see
DRUM RACKS WARNING A, Pg. 459
7
DRUM-RACK-2 2 45½" x 29 /8" x 12¾" 1,600 lb. 90 model DRUM-RACK-2 DRUM HANDLING EQUIPMENT & SPECIALTY CONTAINERS
with DR-CART-2
7
DRUM-RACK-3 3 71½" x 29 /8" x 12¾" 2,400 lb. 101 New
DRUM-RACK-2-G 2 45½" x 29 /8" x 12¾" 1,600 lb. 90
7
DRUM-RACK-3-G 3 71½" x 29 /8" x 12¾" 2,400 lb. 105
7
DRUM-RACK-2-SS 2 45½" x 29 /8" x 12¾" 1,600 lb. 90
7
DRUM-RACK-3-SS 3 71½" x 29 /8" x 12¾" 2,400 lb. 101
7
PORTABLE DRUM DOLLIES*
DR-CART-2 2 30 /8 x 46½" x 14 /16 " 1,600 lb. 102
9
5
DR-CART-3 3 30 /8 x 72½" x 14 /16 " 2,400 lb. 155
5
9
PORTABLE DRUM CARTS*
DR-CART-2-HLK 2 30 /8" x 54 /16" x 39 /16" 1,600 lb. 102
1
5
13
DR-CART-3-HLK 3 30 /8" x 80 /16" x 39 /16" 2,400 lb. 155
5
3
13
*DRUM RACKS SOLD SEPARATELY
Horizontal Drum Storage Racks New
Horizontal Drum Storage Racks provide orderly storage for 30 & 55 gallon drums.
Constructed of heavy duty steel angle and cross bracing is provided for extra strength. The
uprights keep drums from accidental roll off and allows forklift entry from the front or rear.
Four (4) anchor pads help to prevent tipping. Color is yellow with blue cross braces. Survey
sheet for model DRK-SRS-2 available on page 334. Ships knock-down, assembly required.
Optional drum cradle
MODEL OVERALL SIZE UNIFORM WEIGHT DRK-PRDC-42-R and
NUMBER DESCRIPTION (W x D x H) CAPACITY (POUND) drip pan with steel
DRK-1-3 3-DRUM RACK 34 /8" x 34 /16" x 74 /16" 2,400 lb. 205 holder DRK-PRDC-DPN
13
7
9
DRK-2-2 4-DRUM RACK 60 /16" x 34 /16" x 53 /16" 3,200 lb. 208
13
1
7
DRK-3-2 6-DRUM RACK 85 /16" x 34 /16" x 53 /16" 4,800 lb. 274
13
1
15
DRK-2-3 6-DRUM RACK 60 /16" x 34 /16" x 74 /16" 4,800 lb. 268
7
9
13
DRK-3-3 9-DRUM RACK 85 /16" x 34 /16" x 74 /16" 7,200 lb. 359
13
9
15
DRK-SRS-2* 2-DRUM RACK 61½" x 35½" x 31¼" 1,600 lb. 195
model DRK-1-3
DRK-PRDC-42-R OPTIONAL REVOLVING DRUM CRADLE 800 lb. 28 shown with optional
DRK-PRDC-DPN OPTIONAL DRIP PAN W/ STEEL HOLDER --- 5 drip pan and cradle.
*THREE IS THE RECOMMENDED NUMBER THAT CAN BE STACKED ON TOP OF EACH OTHER. (4) Anchor Pads Drums not included.
Pallet Rack Drum Cradles
Pallet Rack Drum Cradles convert standard (42 inch) pallet racks into a versatile
horizontal drum cradle. The unit works with either box beams or step beams. Accepts 30
and 55 gallon steel drums. The drum angle is adjustable by using the height-adjustment
turn knobs (sloping drum allows user to get 3% more fluid out). Works well with the model PRDC-42
Hydraulic Drum Stacker and the Drum Positioner. Steel construction with baked-in
powder-coated toughness.
Model PRDC-42-R features 3" diameter poly rollers that allow manual drum rotation, model PRDC-42-R
making faucet and vent installation more convenient.
Model PRDC-DPN includes brackets and prevents leaks from going onto the floor. model PRDC-42
shown with optional
1
3
Usable dimensions: 9¾"W x 7 /8"L x 4 /16"H. Drum Faucet, model JDFT
(see page I-33)
MODEL OVERALL SIZE ACCEPTABLE WEIGHT
NUMBER (W x L x H) DRUM TYPES (POUND)
PRDC-42 15 /8" x 42½" x 5 /8" 30 & 55 GALLON STEEL 36
7
5
PRDC-42-R 17 /8" x 42½" x 6 /16" 30 & 55 GALLON STEEL 58
3
15
PRDC-DPN OPTIONAL DRIP PAN W/ STEEL HOLDER (12"W x 14 9 / 16 "L x 11 9 / 16 "H) 5
PRDC-RK-RF PALLET RACK DRUM CRADLE ROLLER KIT 4
