DRUM HANDLING EQUIPMENT & SPECIALTY CONTAINERS
Round All-Fiber Drums

Lightweight, cost effective design for an alternative to steel drums. For use with dry or solid
materials. All-fiber construction. Does not include any steel components. Features flat tops
and bottoms for better stacking to save storage space. FDR-30 and FDR-55 include a bag
inside of drum.
MODEL VOLUME UNIFORM UN WEIGHT
NUMBER CAPACITY CAPACITY DIAMETER HEIGHT SPECIFICATIONS (POUND)
FDR-5 5 GAL 130 lb. 11 /8" 12 /8" UN 1G/X60/S 4
5
3
FDR-12 12 GAL 130 lb. 12 /8" 22 /16" UN 1G/X60/S 7
13
7
FDR-30 30 GAL 260 lb. 18 /8" 26" UN 1G/Y92/S 15
7
FDR-55 55 GAL 260 lb. 21 /8" 35 /8" UN 1G/Y100/S 21
1
7
Fiber Drums
A lightweight and cost effective alternative to steel drums. Open Head Fiber Drums are a great
choice for storage and shipping of dry or solid materials. Steel chime reinforces the top and
bottom to keep drum shape and secure contents. Lock rim side lever lock with steel lid cover.
MODEL VOLUME UNIFORM UN WEIGHT
NUMBER CAPACITY CAPACITY DIAMETER HEIGHT SPECIFICATIONS (POUND)
FD-15 15 GAL 150 lb. 16" 20" UN 1G/Y120/S 8
1
model FD-15 model FD-30 FD-30 30 GAL 225 lb. 19" 27 /4" UN 1G/Y172/S 14
Steel Drums Standard and U.N. Rated
Steel Drums
Quality cold rolled drums meet most U.N. requirements for shipping and packaging. Drum
interior is coated with a corrosion inhibitor. Open head drums have removable lids and 12
gauge bolt ring closure. Drums have a 2" and ¾" bung. Additional sizes and stainless steel
drums available, contact factory. Steel surcharges may apply, contact factory.
Stainless Steel Drums
High quality 304 stainless drums are finished in a 2B polish. Meets most U.N. requirements
CLOSED HEAD OPEN HEAD for shipping and packaging. Excellent corrosion resistance makes these stainless steel drums
STEEL DRUM STEEL DRUM superior for storage and shipping of foods and chemicals. Open head drums have removable
lids and 12 gauge bolt ring closure. 2" and ¾" bung standard.

Quick Release Lever Option
This option is used with open head drums only. Lever automatically tightens drum lids to
QUICK RELEASE
LEVER OPTION U.N. specifications. Replaces standard 12 gauge bolt ring closure.
STANDARD STEEL DRUMS
MODEL VOLUME GAUGE UN UN WEIGHT
NUMBER CAPACITY TOP/BODY/BOTTOM STYLE SOLID LIQUID (POUND)
SD-30-OH-02 30 GALLON 20 / 20 / 20 OPEN HEAD 1A2 / X200 / S 1A2 / Y1.5 / 150 26
SD-30-OH-05 30 GALLON 18 / 18 / 18 OPEN HEAD 1A2 / X235 / S 1A2 / Y1.5 / 150 33
SD-30-OH-07 30 GALLON 16 / 18 / 18 OPEN HEAD 1A2 / X235 / S 1A2 / Y1.5 / 150 35
SD-30-OH-07-Q 30 GALLON 16 / 18 / 18 OPEN HEAD 1A2 / X235 / S 1A2 / Y1.5 / 150 35
SD-55-OH-04 55 GALLON 18 / 20 / 20 OPEN HEAD 1A2 / Y425 / S 1A2 / Y1.2 / 100 38
SD-55-OH-06 55 GALLON 18 / 18 / 18 OPEN HEAD 1A2 / X435 / S 1A2 / Y1.5 / 150 48
SD-55-OH-07 55 GALLON 16 / 18 / 18 OPEN HEAD 1A2 / X400 / S 1A2 / Y1.5 / 150 50
SD-55-OH-07-Q 55 GALLON 16 / 18 / 18 OPEN HEAD 1A2 / X400 / S 1A2 / Y1.4 / 150 50
SD-55-OH-08 55 GALLON 16 / 16 / 16 OPEN HEAD 1A2 / X430 / S 1A2 / Y1.5 / 175 60
SD-55-OH-08-Q 55 GALLON 16 / 16 / 16 OPEN HEAD 1A2 / X430 / S 1A2 / Y1.4 / 175 60
SD-30-TH-08 30 GALLON 20 / 20 / 20 CLOSED HEAD N/A 1A1 / Y1.5 / 300 26
SD-30-TH-13 30 GALLON 16 / 20 / 16 CLOSED HEAD N/A 1A1 / Y1.8 / 300 31
SD-55-TH-13 55 GALLON 20 / 20 / 20 CLOSED HEAD N/A 1A1 / Y1.2 / 200 37
SD-55-TH-15 55 GALLON 18 / 18 / 18 CLOSED HEAD N/A 1A1 / Y1.8 / 300 48
SD-55-TH-16 55 GALLON 16 / 16 / 16 CLOSED HEAD N/A 1A1 / Y1.8 / 300 60
SUFFIX “Q” INDICATES THE QUICK RELEASE LEVER OPTION
STAINLESS STEEL DRUMS
MODEL VOLUME GAUGE UN UN WEIGHT
NUMBER CAPACITY TOP/BODY/BOTTOM STYLE SOLID LIQUID (POUND)
SSD-30-TH-03 30 GALLON 18 / 18 / 18 CLOSED HEAD N/A 1A1 / X1.2 / 300 33
SSD-30-OH-04 30 GALLON 18 / 18 / 18 OPEN HEAD 1A2 / X225 / S 1A2 / Y1.5 / 150 35
SSD-55-OH-01 55 GALLON 16 / 16 / 16 OPEN HEAD 1A2 / X430 / S 1A2 / Y1.5 / 200 60
SSD-55-TH-03 55 GALLON 16 / 16 / 16 CLOSED HEAD N/A 1A1 / X1.8 / 300 48
SSD-55-TH-04 55 GALLON 16 / 16 / 16 CLOSED HEAD N/A 1A1 / X1.8 / 550 60
