Page 302 - Vestil Catalog 112

308
DRUM HANDLING EQUIPMENT & SPECIALTY CONTAINERS
Drum Stand

Drum Stand provides economical and convenient portability. These stands offer a uniquely
designed understructure that allows for transporting of drums with either a pallet truck or fork
truck. Accepts steel, plastic, and fiber drums.
The Drum Stand also allows for single drum stacking for easy storage of drums up to three (3)
model DRUM-ST high (empty stands are nestable and stackable). All welded steel construction. Stands include a
safety yellow baked-in powder-coated toughness.

MODEL ACCEPTABLE OVERALL SIZE UNIFORM WEIGHT
USE WITH NUMBER DRUM SIZE (W x H) CAPACITY (POUND)
PALLET TRUCKS
7
DRUM-ST 55 GALLON 24 /8" x 6" 1,500 lb. 40

USE WITH Overpack Drum Dollies
FORK TRUCKS
Transport containment units with Overpack Drum Dollies, series DRUM-SP. Designed to
hold drum spill containers. Dollies roll smoothly on four (4) swivel casters. Steel construction.
Does NOT work with the SCC-series Overpack Containers.

MODEL OUTSIDE INSIDE CASTER UNIFORM WEIGHT
NUMBER DIAMETER DIAMETER TYPE CAPACITY (POUND)
3
DRUM-SP-28-12-C 28 /8" 28" STEEL 1,200 lb. 34
3
DRUM-SP-28-9-H 28 /8" 28" HARD RUBBER 900 lb. 32
5
OVERPACK DRUM DOLLY DRUM-SP-32-12-C 32" 31 /8" STEEL 1,200 lb. 37
5
series DRUM-SP DRUM-SP-32-9-H 32" 31 /8" HARD RUBBER 900 lb. 34
Mobile Drum Dollies

Transport ordinary or specialty drums easily with these multipurpose Drum Dollies.
Various constructions, designs, caster types, and sizes to accommodate your application.
Assembly required.
A) The Octo Drum Dolly, model OCTO-55-CI, will transport 55 gallon drums weighing
up to 2,000 pounds. Rolls on eight (8) 4" x 1¼" cast iron swivel casters for maximum
stability.
B) Heavy-Duty Drum Dolly, model DRUM-HD, can transport 55 gallon drums. With
a capacity of 2,000 pounds, this dolly will transport your heavier drums from location to
A location. Four (4) 4" x 2" locking swivel glass-filled nylon casters with brakes standard.
C) Adjustable Drum Dollies, series DRUM-X, accommodates 30, 55, 85, and 95 gallon
drums or adjusts to fit multiple square and rectangular crates. Blue baked-in powder-
coated toughness.

E
B

C D E F
MODEL ACCEPTABLE DRUM UNIFORM WEIGHT
TYPE NUMBER DESCRIPTION SIZE (GALLON) CASTER TYPE HEIGHT CAPACITY (POUND)
A OCTO-55-CI OCTO DOLLY 55 CAST IRON 2,000 lb. 40
B DRUM-HD HEAVY-DUTY 55 GLASS-FILLED NYLON 2,000 lb. 40
C DRUM-X-H ADJUSTABLE 30, 55, 85 & 95 HARD RUBBER 5 /16" 1,000 lb. 19
5
C DRUM-X-C ADJUSTABLE 30, 55, 85 & 95 CAST STEEL 5 /16" 1,200 lb. 22
1
D DDO-P103-HT3 CAST IRON 55 & 30 HARD RUBBER 6 /16" 550 lb. 37
3
D DDO-P103-SS3 CAST IRON 55 & 30 SEMI-STEEL 6 /8" 600 lb. 37
1
E DRUM-SS-55-H STAINLESS STEEL 55 HARD RUBBER 6" 800 lb. 23
E DRUM-FSD-SS-5-N STAINLESS STEEL 55 NYLON 7" 1,100 lb. 20
F DRUM-DRH-HR WITH HANDLE 5, 30 & 55 HARD RUBBER 6¼" 1,000 lb. 23
