166 Heavy-Duty Banding Cart
PACKAGING EQUIPMENT and standard 27" wide pallet trucks. Includes lifting eye for use with overhead crane. Also comes

Heavy-duty "industrial grade" strapping and banding cart includes fork pockets for use with lift trucks
standard with a steel tool storage tray (18"W x 7"D x 3½"H usable) and 16" diameter foam wheels.
Works with strapping core sizes of 16" x 3", 16" x 6" and 8" x 8", available on page 168.

WEIGHT
ACCEPTABLE
OVERALL SIZE
MODEL
STRAPPING
NUMBER
(POUND)
(W x D x H)
38" x 26 /16" x 48 /16"
STEEL & POLY
131
13
7
STRAP-FP
model STRAP-FP
Vertical/Horizontal Strapping Cart
Unique cart allows the operator to apply strapping both vertically and horizontally around the load.
For use with both steel and poly strapping. To use, engage outer detents (disengaging inner) and
turn the removable handle until strap is in the horizontal position. Once in the horizontal position,
disengage the outer detents and engage the inner detents. The strap can now be raised and lowered
from 28" down to 8" with the same handle. Each unit comes standard with 10" x 2½" semi-pneumatic
wheels. The equipment tray measures 14"W x 6"L x 4½"D. Works with strapping core sizes of 16" x
3", 16" x 6" and 8" x 8", available on page 168.
MODEL OVERALL SIZE MAXIMUM ACCEPTABLE WEIGHT
model
STRAP-VH NUMBER (W x D x H) DIAMETER STRAPPING (POUND)
9
11
STRAP-VH� 26 /16" x 30 /16" x 47½" 24" STEEL & POLY 176
Manual Pallet Probe Strapping Cart

• Increase Productivity • Economical, Fast, Easy • Low Maintenance
The Manual Pallet Probe Strapping Cart is a quick answer to a long time dilemma - getting poly
strapping through your pallet. To use, transport cart to your loaded pallet, extend arm, and run
strapping to end clip. After strapping is secure, roll cart probe into pallet along center stringer. The
strapping arm will then protrude out the other end allowing the operator to pull the strapping up and
over the pallet. Unit accepts polypropylene strapping. Tray size is 19"W x 5¾"D. Overall material
diameter is 16" with a minimum of 13¾". Works with poly strapping core sizes of 16" x 3", 16" x 6"
and 8" x 8", available on page 168.

MODEL ARM LENGTH MAXIMUM ACCEPTABLE WEIGHT
NUMBER RETRACTED/EXTENDED DIAMETER STRAPPING (POUND)
STRAP-P2� 40" TO 64" 24" POLY 132
model
STRAP-P2
Strapping Carts

Universal strapping carts are designed for use with Poly and Steel strapping.
STRAP-PS-HD features unique multi-tier discs for use with strapping core sizes of 16" x 3", 16" x 6"
and 8" x 8". Cart includes storage tray and two (2) 8" x 2" hard rubber wheels for easy portability.
Powder coat finish. Poly and steel strapping available separately on page 168.
STRAP-PS-P is a lightweight strapping cart with plastic disc and integral tool tray. Designed for use
with poly strapping that has a core size of 8" x 8" see page 168. Great for everyday use around the
warehouse, including box sealing and bundle applications. Two (2) 8" x 2" plastic wheels for easy
maneuvering.

model
STRAP-PS-HD MODEL ACCEPTABLE OVERALL SIZE WEIGHT
NUMBER STRAPPING (W x D x H) (POUND)
7
STRAP-PS-HD� STEEL & POLY 24 /8" x 20½" x 43" 58
STRAP-PS-P� POLY 18½" x 20" x 38" 25
model
STRAP-PS-P
