Wash Down Floor Scales 115V 1-PHASE STANDARD

Ideal for food, chemical, and pharmaceutical applications, these scales can withstand daily wash
down. Non-metallic deck insert, type 304 stainless steel frame, feet, and bolts standard. Also comes
with stainless steel NTEP load cells and junction box. Easiest "clean-in-place" scale on the market.
Just lift out the 1" thick polyethylene deck insert, leaving the stainless steel scale frame in place, and
hose down! Accuracy to NIST H44. Indexing accuracy is +/- 0.1% of applied load or 1 division. PACKAGING EQUIPMENT
The digital display is powered by 115V, 1-phase AC power, cord included.

MODEL UNIFORM PLATFORM SIZE WEIGHT
NUMBER CAPACITY (W x L x H) (POUND)
SCALE-LT-44-5K 5,000 lb. 48" x 48" x 4" 296
SCALE-LT-55-5K 5,000 lb. 60" x 60" x 4" 336
SCALE-LT-44-10K 10,000 lb. 48" x 48" x 4" 351
SCALE-LT-55-10K 10,000 lb. 60" x 60" x 4" 391
Stainless Steel Scales 115V 1-PHASE STANDARD

All purpose stainless steel floor scales are designed to withstand the widest variety of demanding
industrial applications, including pharmaceutical, heavy wash down, food processing, chemical, and
hazardous areas. Heavy duty Type 304 structural steel construction with stainless steel enclosure,
hardware, and feet. Uses four hermetically sealed, stainless steel NTEP load cells. Indexing accuracy
is +/- 0.1% of applied load or 1 division. The digital display is powered by 115V, 1-phase AC power,
cord included. Smooth top standard, diamond plate available.

MODEL UNIFORM PLATFORM SIZE WEIGHT
NUMBER CAPACITY (W x L x H) (POUND)
SCALE-STS-44-5K 5,000 lb. 48" x 48" x 3½" 384
SCALE-STS-55-5K 5,000 lb. 60" x 60" x 3½" 419
SCALE-STS-44-10K 10,000 lb. 48" x 48" x 3½" 439
SCALE-STS-55-10K 10,000 lb. 60" x 60" x 3½" 474

Heavy-Duty Domestic Floor Scales 115V 1-PHASE STANDARD
Heavy-duty, 10,000 pound capacity bases utilize a strong 2" channel perimeter and 7" at 9.8 pounds
per foot channel understructure. Plate features up to /8" tread and the load cells are 5K-LE.
3
1
20,000 lb. capacity bases utilize /2" thick diamond plate with 10K-LE load cells.
SCALE-SC20-44-20K utilizes 7" at 9.8 pounds per foot channel under structure and the same
perimeter, while the SCALE-SC20-55-20K uses 8" at 20 pounds per foot channel understructure
and perimeter. These are the ultimate, all around heavy bases! Contact factory for ramp options.
Indexing accuracy is +/- 0.1% of applied load or 1 division. The digital display is powered by 115V,
1-phase AC power, cord included.
20,000 LB. CAPACITY SCALE SHOWN WITH
OPTIONAL APPROACH RAMPS. CONTACT
MODEL UNIFORM PLATFORM SIZE WEIGHT FACTORY FOR RAMP INFORMATION.
NUMBER CAPACITY (W x L x H) (POUND)
SCALE-DH10-44-10K 10,000 lb. 48" x 48" x 5" 450
SCALE-DH10-55-10K 10,000 lb. 60" x 60" x 5" 650
SCALE-SC20-44-20K 20,000 lb. 48" x 48" x 5½" 654
SCALE-SC20-55-20K 20,000 lb. 60" x 60" x 5½" 1183

Low Profile Floor Scales 115V 1-PHASE STANDARD
Low Profile Floor Scales are ideal for shipping and receiving areas. Industrial grade heavy duty
mild steel platform scale ensures durability that will withstand years of daily use. Features an
anti-slip rugged steel diamond plate surface with heavy duty welded channel support. Scale has
a powder coat finish and can be pit mounted or free standing. It also has adjustable leveling feet
standard and operator controls for zero, tare, unit, net/gross, and print. Unit converts to pound
or kilograms with a deluxe scale indicator. The mobile digital display stand is adjustable to 42"
height and powered by six (6) AA batteries or 115V, 1-phase AC power, cord included.

MODEL UNIFORM PLATFORM SIZE INDEXING WEIGHT
NUMBER CAPACITY (W x L x H) ACCURACY (POUND)
VLPFS-2� 2,000 lb. 36" x 36" x 4" 0.5 lb. 200
VLPFS-4A� 4,000 lb. 48" x 48" x 4" 1 lb. 280
VLPFS-4B� 4,000 lb. 60" x 60" x 4" 1 lb. 446
VLPFS-20� 20,000 lb. 96" x 120" x 6¾" 1 lb. 2200
VLPFS-R-3636� APPROACH RAMP 36"L x 36"W, 4.45° ANGLE 160
VLPFS-R-3648� APPROACH RAMP 36"L x 48"W, 4.45° ANGLE 188 SHOWN WITH TWO APPROACH RAMPS
VLPFS-R-3660� APPROACH RAMP 36"L x 60"W, 4.45° ANGLE 208 APPROACH RAMPS SOLD EACH
VLPFS-R-3696� APPROACH RAMP 36"L x 96"W, 10° ANGLE 430
