Overpack Containers
Overpack Containers are a great asset when maintaining and moving waste materials. The
unit is constructed of low density polyethylene for strength and durability. Suitable for use
with 55 gallon steel or plastic drums. The containment can be moved by utilizing a fork
truck or other lifting devices. Works with DRUM-ST, DRUM-HD, DRUM-X-H, and OVERPACK CONTAINER
model SCC-65-YL
DRUM-X-C.
Optional Drum Containment Cover available separately. To attach simply place cover
onto the drum containment and snap-on until latched. Units can be stacked/nested for
storage and shipping.
MODEL OVERALL SIZE SUMP UNIFORM WEIGHT
NUMBER DESCRIPTION (W x L x H) CAPACITY CAPACITY (POUND)
SCC-65-YL CONTAINER, YELLOW 36¼" x 36¼" x 29½" 65 GALLON 800 lb. 32
SCC-65-OR CONTAINER, ORANGE 36¼" x 36¼" x 29½" 65 GALLON 800 lb. 32 CONTAINER COVER
model SCC-65-CVR-YL
5
SCC-65-CVR-YL COVER, YELLOW 37" x 37" x 11 /8" -- -- 15
5
SCC-65-CVR-OR COVER, ORANGE 37" x 37" x 11 /8" -- -- 15 DRUM HANDLING EQUIPMENT & SPECIALTY CONTAINERS
Fuel Tank Containment with Drain
Complete containment for 275 & 550 gallon oval tanks, indoors or outdoors! Eliminate costly
spills while storing fuels, oils, and other hazardous liquids. Rugged, all polyethylene construction
will not rust or corrode. Optional Pull Over Cover available.
MODEL OVERALL SIZE INSIDE TOP INSIDE BOTTOM WEIGHT model OCT-275 with
NUMBER (W x D x H) (W x D) (W x D) (POUND) Optional Pull Over Cover
OTC-275 84½" x 43¾" x 29" 80" x 39" 73" x 31" 90
OTC-550 87" x 60" x 33" 82" x 54" 75¾" x 47¾" 108
OTC-CVR275 OPTIONAL PULL OVER COVER FOR OTC-275 ONLY 8
Drum Grab
Designed exclusively for lifting closed and open-head 55 gallon steel drums with a
secured lid installed. Not for use on open-head drums without a lid. This product works on
select 55 gallon plastic and fiber drums with a top lip strong enough to hold the weight
of the drum. Designed for quick and easy one person operation, with drum in a vertical
position. The narrow profile design is great for picking up drums packed close together.
The three-arm ductile-iron design offers maximum strength and simplicity allowing the
centering of the drum under the lifter. The polyurethane "spring" loop keeps the lifter
securely engaged to the drum, which is especially beneficial when using the lifter in a
rough environment including swinging, bouncing, and incidental collisions. Unit must
be manually disengaged from the drum when finished with use.
MODEL ACCEPTABLE UNIFORM WEIGHT
NUMBER DRUM TYPE CAPACITY (POUND)
DRUM-GRAB STEEL CLOSED & OPEN-HEAD W/LID 2,200 lb. 20
Multi-Purpose Overhead Drum Lifters/Wrenches
Simple three-arm design for use with closed head 30 and 55 gallon steel, plastic,
and fiber drums with a top lip. Each removable arm also functions as a wrench
for use on drum plugs, faucets, and rim ring bolts. Mechanical operation.
Requires assistance from an overhead lifting device. Baked-in powder-coated
toughness. Steel construction.
Model PDL-800-M-BR features a bronze, spark resistant alloy. model PDL-800-M model PDL-800-M-BR
CA Residents see
WARNING A, Pg. 459
MODEL UNIFORM WEIGHT
NUMBER CONSTRUCTION CAPACITY (POUND)
PDL-800-M STEEL 800 lb. 20
PDL-800-M-BR BRONZE ALLOY 800 lb. 18
