60 Heavy-Duty Portable Evaporative Cooler 115V 1-PHASE STANDARD
FACILITY MAINTENANCE FACILITIES MAINTENANCE approximately 8 hours without being connected to an external water source. Water is supplied to the

These Portable Evaporative Coolers have large internal water reservoirs that allow units to operate
internal tank from a standard ¾" water hose or from optional water tank. Water level in internal tank
is controlled by the unit's float valve. Maintenance free submersible water pump. 8" thick evaporative
media pads are easily accessible for routine maintenance. Roto-molded corrosion free polyethylene
housing. 20 foot long, 16 ga. 3 conductor cord with GFCI plug. Thermally protected, permanently
lubricated fan motor. Variable 3 speed. Weather tight fan and pump control switches. 4" heavy-duty
casters; two (2) locking, two (2) non-locking. ETL listed.

UNIT
INTERNAL
OVERALL SIZE
WEIGHT
MODEL
SQ. FEET
CFM
NUMBER
SIZE
(W x L x H)
HP
TS-EVAP-36HD BLADE MOTOR AMPS 12500 EFFECTIVE WATER TANK 67" x 34½" x 77" (POUND)
15.0
60 gal.
0.7
36"
307
3125
Variable Speed Air Curtains
These Heavy Duty Air Curtains can be used above entry doors and industrial warehouse doors to prevent
loss of cool air and maintain a clean environment. These curtains contain a heavy duty 20 gauge rigid steel
cabinet, with baked on epoxy powder coat paint for durability. Motor is a heavy duty, PSC, direct drive high
efficiency, and signed for use with SCR controllers. Motors are permanently lubricated for long life and have
thermal over load protection. SCR speed controller supplied on all units compatible with the motor with low
end adjustment for air volume control and savings in power consumption. These heavy duty units have a ¾
HP motor, 120V power and can go up to a 12’ high doorway. Heating options available, contact factory.
MODEL DIMENSIONS CFM WEIGHT
NUMBER WIDTH x HEIGHT (LOW x HIGH) (POUND)
ACURT-36 36" x 16" (1 ACURT-36) 819 / 2672 77
ACURT-48 48" x 16" (1 ACURT-48) 906 / 4611 85
ACURT-60 60" x 16" (1 ACURT-60) 1126 / 5763 93
ACURT-72 72" x 16" (2 ACURT-36's) 1638 / 5344 154
ACURT-96 96" x 16" (2 ACURT-48's) 1812 / 9222 170
ACURT-108 108" x 16" (3 ACURT-36's) 2457 / 8016 231
ACURT-120 120" x 16" (1 ACURT-48 & 2 ACURT-36's) 2544 / 9955 239
Quartz Infrared Spot Heaters 1-PHASE STANDARD
Keep cool work areas well heated with these Infrared Heaters. The quartz tube radiates a blanket of heat
in a 60° symmetrical pattern. Unit includes; gold aluminum reflector and end caps, mounting chains,
S-hooks, and a cord set with plug. Units can be hung from the ceiling with mounting chains. Meets
OSHA standards and is ETL C/US listed. Outdoor and indoor rated, outdoor use needs to be protected
from the elements using a solid overhang.

MODEL WEIGHT
NUMBER WATTS VOLTS PHASE BTU's (POUND)
VCH-46C 1500 120 1 5120 9
VCH-57C 3000 240 1 10239 11
VCH-WG46 S.S. WIRE GUARDS (use with model VCH-46C) 2
VCH-WG57 S.S. WIRE GUARDS (use with model VCH-57C) 2

Portable Electric Heaters
model CFFH-240 1-PHASE STANDARD
Portable Electric Heaters are lightweight and have an easy grip handle for convenience. These heaters are
perfect for office, or small spot heating applications. They include a 6 foot long 3 conductor cord and
temperature control thermostat. Model CFFH-240 has a 20 amp plug configuration, which is great for
construction sites. Model FFH-118 and CRFH-198 meet OSHA standards and are ETL C/US listed, while
CFFH-240 is only UL C/US listed. Indoor use only.

MODEL OVERALL SIZE NUMBER WEIGHT
NUMBER (W x D x H) OF SETTINGS VOLTAGE/PHASE BTU's (POUND)
FFH-118 10" x 9½" x 16" 2 HEAT / 1 FAN 120, 1PH 5120 10
CRFH-198 11" x 12" x 15" 3 HEAT 120, 1PH 5120 10
5
model FFH-118 model CRFH-198 CFFH-240 10 /8" x 10" x 12¾" 2 HEAT 240/208, 1PH 13648 15
