57
Expand-A-Gates
Designed to set up quickly and easily wherever and whenever they are needed. Ideal for
preventing potential accidents. Lightweight design allows personnel to quickly retrieve the
gate and limit access to unsafe areas. Smooth operating scissor action. Interlocking and
nestable. Suffix -C features casters. Suffix -W features one swivel caster with a wall/rack
mounting kit. Model PEXGATE is constructed of heavy-duty molded yellow and black FACILITY MAINTENANCE
plastic. One side of gate includes reflectors for better visibility. End pieces are hollow and
may be filled with liquid for added weight. Assembly required.
model EXGATE-30
OVERALL
MODEL COLLAPSED EXPANDED *OVERALL WEIGHT
NUMBER WIDTH GATE WIDTH HEIGHT (POUND)
STEEL CONSTRUCTION
EXGATE-30� 19¾" 139" 38" 55
1
EXGATE-30-C� 19¾" 139" 40 /8" 57
5
EXGATE-30-W� 20 /16" 139" 38 /16" 61
5
EXGATE-W-KIT WALL MOUNT KIT 5
ALUMINUM CONSTRUCTION
ALEXGATE-30� 19¾" 139" 38" 25 STEEL CONSTRUCTION
1
ALEXGATE-30-C� 19¾" 139" 40 /8" 30
5
5
ALEXGATE-30-W� 20 /16" 139" 38 /16" 34
ALEXGATE-W-KIT WALL MOUNT KIT 5
PLASTIC CONSTRUCTION
PEXGATE-30� 11½" 122" 38" 12
PEXGATE-30-C� 11½" 122" 40¾" 13 ALUMINUM CONSTRUCTION
*OVERALL HEIGHT WHEN COLLAPSED model ALEXGATE-30-C
Plastic unit is easy to
model EXGATE-30-W Connector for wall mounted unit fill for added weight
model PEXGATE-30 PLASTIC CONSTRUCTION
model PEXGATE-30-C
Industrial Duty Circulator Fans 115V 1-PHASE STANDARD
Two speed, 115V, 1 phase, ball bearing, totally enclosed and permanently lubricated Industrial
Duty Circulator Fan. Pull chain switch with a 12 foot long cord and an SJT type 3 conductor
cord. Meets OSHA standards and is ETL C/US listed. ¼ HP electric motor.
MODEL BLADE MOUNTING AMPS CFM CFM WEIGHT
NUMBER DIAMETER STYLE HIGH HIGH LOW (POUND) model
ICRF-24-P
ICRF-24-P 24" PEDESTAL 2.5 6800 5000 75
ICRF-24-W 24" WALL 2.5 6800 5000 45
ICRF-30-P 30" PEDESTAL 2.7 7900 6000 75
ICRF-30-W 30" WALL 2.7 7900 6000 48
OSCILLATING STYLE
ICRF-24-PO 24" PEDESTAL 2.5 6800 5000 79
ICRF-24-WO 24" WALL 2.5 6800 5000 49
ICRF-30-PO 30" PEDESTAL 2.7 7900 6000 78
ICRF-30-WO 30" WALL 2.7 7900 6000 53
