Light Duty Swinging Traffic Doors

These Light Duty Traffic Doors are assembled with rotationally molded cross-linked
polyethylene. This extremely durable construction is capable of withstanding the wear and
tear associated with high volume traffic areas. These doors are known for their long term
value in supermarkets, retail establishments, and food service operations as they provide a
visual separation, sound barrier, and thermal separation. The door is designed to comply
with all USDA sanitation requirements and is NSF approved. The corrosion resistant LOADING DOCK EQUIPMENT
panel is ideal for wash down applications as it has no gaps or joint seams. The total width
of the light duty traffic doors are 1½" thick.

MODEL SIZE WEIGHT
NUMBER DESCRIPTION (W x H) (POUND)
LDSW-37 SINGLE DOOR PANEL 3' x 7' 200
LDSW-57 DOUBLE PANEL DOOR 5' x 7' 340
LDSW-58 DOUBLE PANEL DOOR 5' x 8' 350
LDSW-67 DOUBLE PANEL DOOR 6' x 7' 360
LDSW-68 DOUBLE PANEL DOOR 6' x 8' 360
LDSW-88 DOUBLE PANEL DOOR 8' x 8' 400

Heavy Duty Swinging Traffic Doors
These multi-purpose lightweight doors are tough enough to take the abuse of personnel,
stock carts, and motorized pallet jacks. The door panels are constructed with 1/8” thick
rotationally molded cross-linked polyethylene outer shell and foamed-in-place Non-CFC
urethane foam core. The panels are corrosion resistant, making it ideal for washdown
applications as it has no gaps or joint seams. The door comes standard with 24” black
bumpers on both sides of the door. Double acting V-cam hinging system operates
smoothly and is virtually maintenance free with its permanently lubricated needle bearing
roller assembly. There is a 1/8” thick polycarbonate window with black aluminum frame
recessed a minimum of 1/8” from the face of the panel to protect the window’s surface
from abrasion caused by passing loads.
MODEL SIZE WEIGHT
NUMBER DESCRIPTION (W x H) (POUND)
HDSW-37 SINGLE DOOR PANEL 3' x 7' 146
HDSW-57 DOUBLE PANEL DOOR 5' x 7' 256
HDSW-58 DOUBLE PANEL DOOR 5' x 8' 280
HDSW-67 DOUBLE PANEL DOOR 6' x 7' 290
HDSW-68 DOUBLE PANEL DOOR 6' x 8' 320
HDSW-88 DOUBLE PANEL DOOR 8' x 8' 400

Economical Overhead Door Warning Barriers
Protect overhead doors from fork trucks and other traffic coming and going throughout
each day. Intended for use as a warning system - not a fork truck stop. Constructed
with tubular steel uprights and a 4" x 4" wooden beam across the top of the guard. The
wooden beam can be easily and inexpensively replaced when damaged. Guard will not
interfere with overhead door. Complete unit is painted high visibility OSHA safety
yellow. Concrete installation kit available.

MODEL USABLE DOOR USABLE DOOR WEIGHT
NUMBER WIDTH (FT.) HEIGHT (FT.) COLOR (POUND)
DWB-88 8 8 YELLOW 358
DWB-810 8 10 YELLOW 475
DWB-910 9 10 YELLOW 490 model DWB-88
DWB-1010 10 10 YELLOW 505
AS-125� ANCHOR BOLTS FOR CONCRETE (1) 1/2" x 5" 1
AS-125-4PK� ANCHOR BOLTS FOR CONCRETE (4) 1/2" x 5" 4
