16 Dock Seals
LOADING DOCK EQUIPMENT The chemically sealed ends prevent moisture infiltration. It is mounted on and bonded to durable (POUND)

The superior 36 oz. nylon reinforced vinyl facing has a higher tear strength than equivalent weight hypalon.
wolmanized wood and contains a full height air escape tunnel. The unit consists of a three (3) piece
construction (12" high header - sides beveled with 9½" width at the wall and 12" width at the face) and a
through the wall installation kit that is included. 5" maximum compression is recommended. Application
with a flush dock to building in conjunction with an Edge-O-Dock, use a twenty (20) inch projection Dock
Seal. Units are non-returnable.

OVERALL
OVERALL
WEIGHT
MODEL
WIDTH
HEIGHT
PROJECTION
NUMBER
series D-150
108"
D-150-10�
11"
108"
214
120"
D-150-11�
108"
120"
D-150-12�
12"
216
108"
D-150-13� 10" DOOR SIZE 8 FEET WIDE x 8 FEET HIGH 120" 212
218
13"
120"
D-150-14� 14" 108" 120" 219
CA Residents see
WARNING B, Pg. 459 D-150-15� 15" 108" 120" 220
D-150-16� 16" 108" 120" 221
DOCK SEAL & SHELTER D-150-17� 17" 108" 120" 222
SURVEY SHEET IS
ON PAGE 48 D-150-18� 18" 108" 120" 249
D-150-19� 19" 108" 120" 251
D-150-20*� 20" 108" 120" 252
*USE IN CONJUNCTION WITH EDGE-O-DOCK LEVELER
MODEL OVERALL OVERALL WEIGHT
NUMBER PROJECTION HEIGHT WIDTH (POUND)
DOOR SIZE 8 FEET WIDE x 9 FEET HIGH
D-350-10� 10" 120" 120" 216
D-350-11� 11" 120" 120" 218
D-350-12� 12" 120" 120" 220
D-350-13� 13" 120" 120" 225
D-350-14� 14" 120" 120" 237
D-350-15� 15" 120" 120" 243
D-350-16� 16" 120" 120" 248
D-350-17� 17" 120" 120" 250
D-350-18� 18" 120" 120" 264
D-350-19� 19" 120" 120" 270
series D-350 D-350-20*� 20" 120" 120" 275
*USE IN CONJUNCTION WITH EDGE-O-DOCK LEVELER
CA Residents see
WARNING B, Pg. 459
Dock Seal/Shelter Combinations
Dock Seal/Shelter Combinations are used with a 96"W x 120"H door. The top header is constructed of
wolmanized lumber and is built with a slope to allow for water run-off. Header measures 114"W with a 30"L
drop curtain. Side (verticals) measure 120" tall and contain high density foam mounted to treated lumber.
The verticals are mounted on wooden boards (the face of the vertical measures 12"W and tapers to 9½" at
wall) allowing wall mounting down the length of the vertical pieces. Application with flush dock to building
in conjunction with an Edge-O-Dock, use a 20" projection Dock Seal. Units are non-returnable.
MODEL OVERALL OVERALL WEIGHT
NUMBER PROJECTION HEIGHT WIDTH (POUND)
series D-150/650 DOOR SIZE 8 FEET WIDE x 10 FEET HIGH
D-150/650-10� 10" 126" 114" 271
• Effective sealing action D-150/650-11� 11" 126" 114" 278
with full height access. D-150/650-12� 12" 126" 114" 285
D-150/650-13� 13" 126" 114" 287
• This versatile unit utilizes D-150/650-14� 14" 126" 114" 290
seal sides and a shelter top.
D-150/650-15� 15" 126" 114" 293
D-150/650-16� 16" 126" 114" 296
D-150/650-17� 17" 126" 114" 298
CA Residents see
WARNING B, Pg. 459 18" 126" 114" 299
D-150/650-18�
D-150/650-19� 19" 126" 114" 302
D-150/650-20*� 20" 126" 114" 305
DOCK SEAL & SHELTER
SURVEY SHEET IS *USE IN CONJUNCTION WITH EDGE-O-DOCK LEVELER
