210 Quick Install Manual Trollies
GANTRY AND JIB CRANES model QIT-2 virtually any S, H, W, and M type I-beam. Width is adjusted with manual screw mechanism.

These trollies are dependable, safe, and easy to use. Designed to easily adjust to the width of
Includes locking ring to prevent trolley width from changing accidentally. Manual screw mechanism
may also be tightened to prevent trolley from moving (similar to a Beam Clamp). Each trolley
includes four (4) rollers with sealed bearings for long life. A lifting eye is located at the bottom of
the trolley for attaching a hoist (not included). Steel construction and painted finish.
WEIGHT
FITS I-BEAM
MODEL
UNIFORM
FLANGE WIDTH
HEADROOM
NUMBER
(POUND)
CAPACITY
3" to 5"
QIT-03�
300 lb.
3" to 5"
6¾"
QIT-06�
13
600 lb.
3" to 5"
13
QIT-1�
6¾"
model QIT-6
14
2,000 lb.
8 /8"
3" to 5"
1
QIT-2�
17
10"
4,000 lb.
QIT-4� 3" to 7½" 6¾" 1,000 lb. 13
3
QIT-6� 3" to 7½" 10 /8" 6,000 lb. 40
QIT-8� 4" to 11¾" 13 /8" 8,000 lb. 68
7
7
QIT-10� 4" to 11¾" 13 /8" 10,000 lb. 68
7
QIT-12� 4" to 11¾" 13 /8" 12,000 lb. 70
Low Profile Manual Trollies
These trollies have been designed to quickly install on virtually any S, H, W, and M type I-beam.
The width of the trolley is adjusted by rotating the center rod with lifting eye clockwise or
counterclockwise. Once hoist is attached, center rod cannot be rotated which prevents trolley width
from accidentally changing. The trolley includes four (4) rollers with sealed bearings. Choose either
push or geared trolley. Geared trolley is ideal for use when precise positioning is required. A lifting
PUSH LOW PROFILE
EYE MANUAL TROLLEY eye is located at the bottom of the trolley for attaching a hoist (sold separately). Steel construction
model E-MT-4 and painted finish. Headroom is measured from bottom of wheel to bottom of hooking eye.
MODEL I-BEAM UNIFORM WEIGHT
NUMBER DESCRIPTION FLANGE HEADROOM CAPACITY (POUND)
E-MT-1� PUSH 2" to 8 /8" 2 /2" 1,000 lb. 12
5
1
5
1
1
E-MT-2� PUSH 2 /2" to 10 /8" 2 /8" 2,000 lb. 20
E-MT-4� PUSH 2 /2" to 8 /8" 3" 4,000 lb. 31
5
1
5
3
E-MT-6� PUSH 3" to 8 /8" 3 /8" 6,000 lb. 52
E-MT-8� PUSH 3" to 9" 4" 8,000 lb. 82
E-MT-10� PUSH 3" to 9" 4" 10,000 lb. 82
1
1
1
E-MT-1-C� GEARED 2 /2" to 5 /2" 4 /2" 1,000 lb. 21
1
1
E-MT-2-C� GEARED 2 /2" to 5 /2" 5" 2,000 lb. 29
E-MT-4-C� GEARED 3" to 6 /2" 6" 4,000 lb. 41
1
3
E-MT-6-C� GEARED 3" to 8" 7 /8" 6,000 lb. 62
GEARED LOW PROFILE E-MT-8-C� GEARED 3" to 9" 8 /8" 8,000 lb. 100
5
EYE MANUAL TROLLEY E-MT-10-C� GEARED 3" to 9" 8 /8" 10,000 lb. 103
5
(FEATURES 10 FT. OF CHAIN)
model E-MT-2-C
Low Headroom Combination Chain Hoist/Trolley
Use this to gain additional raised hook height. Chain hoist hook travel is 10 feet.
Assembly required. Fits on wide flange or S-type I-beam.
MODEL BOTTOM OF ROLLER I-BEAM UNIFORM WEIGHT
NUMBER DESCRIPTION TO TOP OF HOOK FLANGE CAPACITY (POUND)
LOW-1P� PUSH 11¾" 2" - 6" 1,000 lb. 45
LOW-2P� PUSH 13" 2½" - 8" 2,000 lb. 63
LOW-4P� PUSH 16¼" 3½" - 8" 4,000 lb. 92
LOW-6P� PUSH 18¼" 4" - 8" 6,000 lb. 144
LOW-1G� GEARED 11¾" 2" - 6" 1,000 lb. 49
LOW-2G� GEARED 13" 2½" - 8" 2,000 lb. 73
LOW-4G� GEARED 16¼" 3½" - 8" 4,000 lb. 110
LOW-6G� GEARED 18¼" 4" - 8" 6,000 lb. 158
Compact & Lightweight Lever Hoist (disc brake)
New Compact and Lightweight Lever Hoists are ideal for use in confined areas when fastening, fixing
or positioning of light load is required. High impact aluminum alloy housing with all the main
parts made of heat treated alloy steel (more durable and longer life). Advanced gear reduction
system (5 gears in the gear box) enables effortless handling and requires low hand-pull force for
highly reliable lifting. Withstand 1500 cycles with 110% of rated capacity. Features lightweight
high strength grade 100 chain. Heavy duty storage bag included.
MODEL UNIFORM STANDARD MINIMUM DISTANCE HANDLE WEIGHT
model VKX-05-5
NUMBER CAPACITY LIFT (FEET) BETWEEN HOOKS LENGTH (POUND)
7
3
VKX-05-5� 500 lb. 5 7 /8" 5 /4" 6
1
7
VKX-10-5� 1,000 lb. 5 9 /8" 6 /4" 8
