240
Folding Ladders with Wheels
INDUSTRIAL & COMMERCIAL LADDERS
Locking foldable design saves on storage space when ladder is not in use. Ladder folds after
unlocking one spring-loaded detent pin. Once unit is folded, tilt back on wheels for easy
CARBON
STEEL portability. Available in either carbon steel or stainless steel. The steps are perforated to provide
a non-slip surface. The ladders have 7" deep steps and a climb angle of 58°. Stainless steel
model FLAD-2 models are a 202 grade. Complies with ANSI 14.7 and OSHA 1910.29 specifications.

NUMBER TOP STEP UNIFORM WEIGHT MODEL NUMBER MODEL NUMBER
OF STEPS HEIGHT CAPACITY (POUND) CARBON STEEL STAINLESS STEEL
2 20 /8" 350 lb. 31 FLAD-2� FLAD-2-SS�
5
3 30 /4" 350 lb. 39 FLAD-3� FLAD-3-SS�
1
STAINLESS
7
STEEL 4 39 /8" 350 lb. 47 FLAD-4� FLAD-4-SS�

Aluminum Ladder/Carts
These well built Aluminum Ladder/Carts are great for home, office, or store. Rugged aluminum
construction is strong and lightweight. Converts in seconds from ladder to cart. Ladder
uniform capacity is 250 lb., while the hand truck uniform capacity is 130 lb. Nose plate
measures 15" wide. Units roll smoothly on 4" wheels.
MODEL NO. OF OVERALL LADDER OVERALL CART OVERALL FOLDED WEIGHT
NUMBER STEPS (W x D x H) (W x D x H) SIZE (W x D x H) (POUND)
C-130-2� 2 18½" x 20" x 37" 18½" x 14" x 39" 18½" x 3½" x 39" 17
C-130-3� 3 18½" x 29" x 47" 18½" x 18" x 50" 18½" x 3½" x 50" 22
model C-130-2 model C-130-3

Aluminum Step Stands

Ideal for industrial or commercial applications. Strong design yields a uniform capacity of 500
pounds, but is lighter than comparable steel models. Open step design includes extra heavy duty
serrated surface for traction. With rubber tipped legs, this step ladder is ideal for use on many
types of floors. Complies with OSHA 1910.24 specifications.
RAW ALUMINUM FINISH
MODEL NO. OF OVERALL SIZE WEIGHT
NUMBER STEPS (W x D x H) ASSEMBLY (POUND)
SSA-1 1 22 /16" x 14 /8" x 10 /16" WELDED 13
7
7
13
SSA-1W 1 32 /16" x 14 /8" x 10 /16" WELDED 13
7
7
13
SSA-2 2 22 /16" x 24 /16" x 20" WELDED 14
9
13
model SSA-3
SSA-2W 2 32 /16" x 24 /16" x 20" WELDED 19
9
13
SSA-3 3 22 /16" x 34 /16" x 20" WELDED 27
13
9
SSA-3W 3 32 /16" x 34 /16" x 30" WELDED 29
9
13
SSA-2-KD 2 22 /16" x 24 /16" x 20" BOLT TOGETHER 14
9
13
SSA-2W-KD 2 32 /16" x 24 /16" x 20" BOLT TOGETHER 19
9
13
SSA-3-KD 3 22 /16" x 34 /16" x 30" BOLT TOGETHER 29
13
9
SSA-3W-KD 3 32 /16" x 34 /16" x 30" BOLT TOGETHER 29
9
13
YELLOW POWDER COAT FINISH
SSA-1-Y 1 22 /16" x 14 /8" x 10 /16" WELDED 13
13
7
7
SSA-1W-Y 1 32 /16" x 14 /8" x 10 /16" WELDED 13
13
7
7
SSA-2-Y 2 22 /16" x 24 /16" x 20" WELDED 14
13
9
SSA-2W-Y 2 32 /16" x 24 /16" x 20" WELDED 14
13
9
SSA-3-Y 3 22 /16" x 34 /16" x 20" WELDED 27
13
9
SSA-3W-Y 3 32 /16" x 34 /16" x 30" WELDED 30
9
13
model SSA-2-Y
SSA-2-KD-Y 2 22 /16" x 24 /16" x 20" BOLT TOGETHER 14
9
13
SSA-2W-KD-Y 2 32 /16" x 24 /16" x 20" BOLT TOGETHER 14
9
13
SSA-3-KD-Y 3 22 /16" x 34 /16" x 30" BOLT TOGETHER 29
9
13
SSA-3W-KD-Y 3 32 /16" x 34 /16" x 30" BOLT TOGETHER 29
9
13
