Vinyl Strip Doors New

Vinyl Strip Doors help control noise, dust, fumes, and smoke while minimizing
drafts, illnesses, and accidents. The strip doors offer visual clarity without sacrificing
safety and the fire resistant material is self-extinguishing. The material design also
deters UV rays during direct sunlight when applied to loading docks and external
doorways. The simple low cost design is easy to maintain, while reducing heating
and cooling costs. Standard material meets USDA requirements and is great for LOADING DOCK EQUIPMENT
refrigeration applications up to -10 degrees Fahrenheit. All doors are shipped pre-
assembled and ready for installation. Installation hardware not included. Custom
door sizes and material available, contact factory.
HEADER MOUNT
The low temperature strips (see bottom of page) are made of a softer PVC BRACKET
compound, which remains pliable in temperatures as low as -40 degrees Fahrenheit.
Ribbed Material (8" & 12") STANDARD MATERIAL WORKS
Low Temperature Material (-40°F) (4", 6", 8", 12" & 16") IN CONDITIONS -10° TO 140°F
Bronze Weld Screen Material (8" & 12")
Orange Opaque Material (6", 8", 12" & 16")
STRIP DOOR CUT TO ORDER
MATERIAL
STANDARD 2/3 OVERLAP FULL OVERLAP NON-RETURNABLE
HEADER MOUNT / STANDARD OVERLAP HEADER MOUNT / FULL OVERLAP
MODEL DOOR SIZE STRIP STRIP WEIGHT MODEL DOOR SIZE STRIP STRIP WEIGHT
NUMBER (W x H) WIDTH THICKNESS (POUND) NUMBER (W x H) WIDTH THICKNESS (POUND)
TG-600-S-H-96-96 96" x 96" 6" 0.06" 88 TG-600-F-H-96-96 96" x 96" 6" 0.06" 88
TG-600-S-H-96-108 96" x 108" 6" 0.06" 95 TG-600-F-H-96-108 96" x 108" 6" 0.06" 95
TG-600-S-H-108-120 108" x 120" 6" 0.06" 130 TG-600-F-H-108-120 108" x 120" 6" 0.06" 129
TG-600-S-H-120-120 120" x 120" 6" 0.06" 131 TG-600-F-H-120-120 120" x 120" 6" 0.06" 139
TG-600-S-H-120-144 120" x 144" 6" 0.06" 141 TG-600-F-H-120-144 120" x 144" 6" 0.06" 149
TG-600-S-H-144-144 144" x 144" 6" 0.06" 151 TG-600-F-H-144-144 144" x 144" 6" 0.06" 159
TG-800-S-H-96-96 96" x 96" 8" 0.08" 98 TG-800-F-H-96-96 96" x 96" 8" 0.08" 98
TG-800-S-H-96-108 96" x 108" 8" 0.08" 105 TG-800-F-H-96-108 96" x 108" 8" 0.08" 105
TG-800-S-H-108-120 108" x 120" 8" 0.08" 140 TG-800-F-H-108-120 108" x 120" 8" 0.08" 139
TG-800-S-H-120-120 120" x 120" 8" 0.08" 149 TG-800-F-H-120-120 120" x 120" 8" 0.08" 149
TG-800-S-H-120-144 120" x 144" 8" 0.08" 159 TG-800-F-H-120-144 120" x 144" 8" 0.08" 159
TG-800-S-H-144-144 144" x 144" 8" 0.08" 169 TG-800-F-H-144-144 144" x 144" 8" 0.08" 169
TG-1200-S-H-96-96 96" x 96" 12" 0.12" 170 TG-1200-F-H-96-96 96" x 96" 12" 0.12" 125
TG-1200-S-H-96-108 96" x 108" 12" 0.12" 192 TG-1200-F-H-96-108 96" x 108" 12" 0.12" 128
TG-1200-S-H-108-120 108" x 120" 12" 0.12" 241 TG-1200-F-H-108-120 108" x 120" 12" 0.12" 166
TG-1200-S-H-120-120 120" x 120" 12" 0.12" 261 TG-1200-F-H-120-120 120" x 120" 12" 0.12" 191
TG-1200-S-H-120-144 120" x 144" 12" 0.12" 303 TG-1200-F-H-120-144 120" x 144" 12" 0.12" 219
TG-1200-S-H-144-144 144" x 144" 12" 0.12" 353 TG-1200-F-H-144-144 144" x 144" 12" 0.12" 252
TG-1600-S-H-96-96 96" x 96" 16" 0.16" 208 TG-1600-F-H-96-96 96" x 96" 16" 0.16" 208
TG-1600-S-H-96-108 96" x 108" 16" 0.16" 223 TG-1600-F-H-96-108 96" x 108" 16" 0.16" 223
TG-1600-S-H-108-120 108" x 120" 16" 0.16" 414 TG-1600-F-H-108-120 108" x 120" 16" 0.16" 243
TG-1600-S-H-120-120 120" x 120" 16" 0.16" 434 TG-1600-F-H-120-120 120" x 120" 16" 0.16" 243
TG-1600-S-H-120-144 120" x 144" 16" 0.16" 510 TG-1600-F-H-120-144 120" x 144" 16" 0.16" 281
TG-1600-S-H-144-144 144" x 144" 16" 0.16" 601 TG-1600-F-H-144-144 144" x 144" 16" 0.16" 326
WALL MOUNT / STANDARD OVERLAP WALL MOUNT / FULL OVERLAP
MODEL DOOR SIZE STRIP STRIP WEIGHT MODEL DOOR SIZE STRIP STRIP WEIGHT
NUMBER (W x H) WIDTH THICKNESS (POUND) NUMBER (W x H) WIDTH THICKNESS (POUND)
TG-600-S-W-96-96 96" x 96" 6" 0.06" 88 TG-600-F-W-96-96 96" x 96" 6" 0.06" 88
TG-600-S-W-96-108 96" x 108" 6" 0.06" 108 TG-600-F-W-96-108 96" x 108" 6" 0.06" 113
TG-600-S-W-108-120 108" x 120" 6" 0.06" 130 TG-600-F-W-108-120 108" x 120" 6" 0.06" 129
TG-600-S-W-120-120 120" x 120" 6" 0.06" 138 TG-600-F-W-120-120 120" x 120" 6" 0.06" 139
TG-600-S-W-120-144 120" x 144" 6" 0.06" 141 TG-600-F-W-120-144 120" x 144" 6" 0.06" 149
TG-600-S-W-144-144 144" x 144" 6" 0.06" 151 TG-600-F-W-144-144 144" x 144" 6" 0.06" 159
TG-800-S-W-96-96 96" x 96" 8" 0.08" 90 TG-800-F-W-96-96 96" x 96" 8" 0.08" 98
TG-800-S-W-96-108 96" x 108" 8" 0.08" 108 TG-800-F-W-96-108 96" x 108" 8" 0.08" 105
TG-800-S-W-108-120 108" x 120" 8" 0.08" 140 TG-800-F-W-108-120 108" x 120" 8" 0.08" 139
TG-800-S-W-120-120 120" x 120" 8" 0.08" 149 TG-800-F-W-120-120 120" x 120" 8" 0.08" 149
TG-800-S-W-120-144 120" x 144" 8" 0.08" 159 TG-800-F-W-120-144 120" x 144" 8" 0.08" 159
TG-800-S-W-144-144 144" x 144" 8" 0.08" 169 TG-800-F-W-144-144 144" x 144" 8" 0.08" 169
TG-1200-S-W-96-96 96" x 96" 12" 0.12" 170 TG-1200-F-W-96-96 96" x 96" 12" 0.12" 114
TG-1200-S-W-96-108 96" x 108" 12" 0.12" 181 TG-1200-F-W-96-108 96" x 108" 12" 0.12" 146
TG-1200-S-W-108-120 108" x 120" 12" 0.12" 200 TG-1200-F-W-108-120 108" x 120" 12" 0.12" 166
TG-1200-S-W-120-120 120" x 120" 12" 0.12" 261 TG-1200-F-W-120-120 120" x 120" 12" 0.12" 191
TG-1200-S-W-120-144 120" x 144" 12" 0.12" 303 TG-1200-F-W-120-144 120" x 144" 12" 0.12" 219
TG-1200-S-W-144-144 144" x 144" 12" 0.12" 353 TG-1200-F-W-144-144 144" x 144" 12" 0.12" 252
TG-1600-S-W-96-96 96" x 96" 16" 0.16" 223 TG-1600-F-W-96-96 96" x 96" 16" 0.16" 223
TG-1600-S-W-96-108 96" x 108" 16" 0.16" 233 TG-1600-F-W-96-108 96" x 108" 16" 0.16" 233
TG-1600-S-W-108-120 108" x 120" 16" 0.16" 243 TG-1600-F-W-108-120 108" x 120" 16" 0.16" 243
TG-1600-S-W-120-120 120" x 120" 16" 0.16" 253 TG-1600-F-W-120-120 120" x 120" 16" 0.16" 253
TG-1600-S-W-120-144 120" x 144" 16" 0.16" 263 TG-1600-F-W-120-144 120" x 144" 16" 0.16" 263
TG-1600-S-W-144-144 144" x 144" 16" 0.16" 273 TG-1600-F-W-144-144 144" x 144" 16" 0.16" 273
LOW TEMPERATURE MATERIAL / HEADER MOUNT / STANDARD OVERLAP
New LOW TEMPERATURE MATERIAL / HEADER MOUNT / STANDARD OVERLAP
MODEL DOOR SIZE STRIP STRIP WEIGHT MODEL DOOR SIZE STRIP STRIP WEIGHT
NUMBER (W x H) WIDTH THICKNESS (POUND) NUMBER (W x H) WIDTH THICKNESS (POUND)
TG-600-S-H-48-84-LT 48" x 84" 6" 0.06" 52 TG-800-S-H-48-96-LT 48" x 96" 8" 0.08" 66
TG-600-S-H-48-96-LT 48" x 96" 6" 0.06" 56 TG-800-S-H-60-96-LT 60" x 96" 8" 0.08" 74
TG-600-S-H-60-96-LT 60" x 96" 6" 0.06" 64 TG-800-S-H-72-96-LT 72" x 96" 8" 0.08" 82
TG-600-S-H-72-96-LT 72" x 96" 6" 0.06" 72 TG-800-S-H-96-96-LT 96" x 96" 8" 0.08" 98
TG-600-S-H-96-96-LT 96" x 96" 6" 0.06" 88 TG-1200-S-H-96-96-LT 96" x 96" 12" 0.12" 170
TG-800-S-H-36-84-LT 36" x 84" 8" 0.08" 55 TG-1200-S-H-96-120LT 96" x 120" 12" 0.12" 202
TG-800-S-H-48-84-LT 48" x 84" 8" 0.08" 62 TG-1200-S-H-120120LT 120" x 120" 12" 0.12" 261
