112 High Lift Trucks
ERGONOMIC SOLUTIONS model a very steady working platform, minimizing rocking and movement in all directions. Stabilizers 425

Ideal for skids, baskets, and work applications. Electric pump has chrome plated piston. Features
positioned at the rear improved balance, making work easier when lifting and working with heavy
loads. DC powered with 12V battery and a bench top charger. Individual fork width is 6½".
MODEL
MAXIMUM
BATTERY
WEIGHT
OVERALL FORK
UNIFORM
HEIGHT
SIZE (W x L)
(POUND)
NUMBER
CAPACITY
TYPE
31½"
PMC-HIPM-21-DC�
(1) 12V
21" x 45"
2,200 lb.
PMC-HIPM-27-DC
27" x 45"
2,200 lb.
31½"
438
PMC-HIPM-27-DC�
(1) 12V
High Tote Lifter 12V DC STANDARD
A High Tote Lifter is a perfect asset for any food handling atmosphere. The stainless steel
construction is easily cleaned due to its smooth finish. An open fork design allows for simple
inspection for overall complete hygiene. Products can be raised or lowered by utilizing the 12V
DC powered hand pump. When the unit has been raised, it minimizes the amount of bending and
twisting that can occur when products are placed in the improper height location. The wheeled
model scissor base creates a steady base when in position to load or unload merchandise. The overall
ULM-HTL-2149-20
compact design is easily stored when not in use.
MODEL FORK SIZE SERVICE UNIFORM WEIGHT
NUMBER OPERATION (W x L) RANGE CAPACITY (POUND)
ULM-HTL-2149-20 12V DC 21" x 45" 3¾" to 31½" 2,000 lb. 427
Tote-A-Loads
Designed to lift open bottom skids, boxes, and baskets. The manually operated lift is easy to operate.
The foot pump operated lift travels approximately ½" per stroke. To lower unit simply squeeze the
bicycle style grip located on the white push bar. The battery operated lift is ideal for positioning
products at workstation heights for increased productivity. The up/down lever control is conveniently
located on the power unit. DC powered units include one (1) 12V battery, an on-board charger and a
FOOT PUMP
model TAL-260-HD battery charge indicator gauge. Polyurethane swivel casters with brake are standard on all units.
MODEL FORK SIZE UNIFORM SERVICE WEIGHT
NUMBER DESCRIPTION (W x L) CAPACITY RANGE (POUND)
TAL-220-HD� FOOT PUMP 21" x 43½" 2,200 lb. 3½" to 33" 356
TAL-260-HD� FOOT PUMP 27" x 43" 2,200 lb. 3½" to 33" 385
TAL-220-DC� 12V DC 21" x 43" 2,200 lb. 3½" to 33" 471
TAL-260-DC� 12V DC 27" x 43" 2,200 lb. 3½" to 33" 474
12V DC POWERED TOTE-A-LOAD OPTIONS
model TAL-260-DC
MODEL WEIGHT
NUMBER DESCRIPTION (POUND)
TAL-PLATE-21� 21¼" WIDE SOLID PLATFORM TO FIT OVER FORKS 36
TAL-PLATE-27� 27¾" WIDE SOLID PLATFORM TO FIT OVER FORKS 38
Basket & Skid Stackers
SKID ONLY NO PALLET
APPLIES TO ABOVE PRODUCTS ON THIS PAGE Transport open bottom pallets, skids, baskets, and crates with ease. Features an 18" horizontal load
center and overall fork width of 26". Units roll smoothly on 8" x 3" swivel phenolic rear casters.
Handle height is 40". DC powered units include one (1) 12V battery and an on-board charger.
Optional reciprocating air/oil power with foot treadle control available, contact factory.
Reduce worker fatigue and injury with our factory installed Power Traction Drive option. An alternative
to costly fork trucks, the PMSS-PTDS-E includes combination throttle / direction and auto reverse
emergency "belly" switch. This state of the art option allows a single operator to safely and easily move
SKID ONLY products. Maximum speed is 2.5 m.p.h. 24V DC system
MODEL UNIFORM FORK SIZE SERVICE WEIGHT
NUMBER CAPACITY OPERATION (W x L) RANGE (POUND)
NO PALLET PMSS-50-DC 4,000 lb. 12V DC 4" x 36" 3½" to 50" 989
PMSS-50-AC 4,000 lb. 115V AC 4" x 36" 3½" to 50" 989
PMSS-60-DC 4,000 lb. 12V DC 4" x 36" 3½" to 60" 959
PMSS-60-AC 4,000 lb. 115V AC 4" x 36" 3½" to 60" 1032
OPTIONS
PMSS-PTDS-E POWER TRACTION DRIVE SYSTEM 600
