Hand Winch Lift Trucks

Compact lift trucks are designed to lift material to and from
shelves, move office equipment, and install ceiling/wall appliances.
Constructed of durable steel and aluminum. The rugged 4"
wide by 1¾" thick steel forks measure 22" long (20½" O.D.).
Operated by a hand-crank winch that features a reversible handle ERGONOMIC SOLUTIONS
and a hold-down device for securing the carriage during transport.
Forks raise 1" per complete hand crank rotation. The non-
adjustable forks can be inverted to provide different height ranges.
Two (2) non-marking rear wheels, two (2) front swivel casters.
Optional aluminum ladder can be retrofitted or ordered with
A-LIFT. Ladder retracts into unit upright when not in use.
Model A-LIFT-LAD is 20½"W x 57½"H, while model
A-LIFT-EHP-LAD is 20⅝"W x 69½"H with 11¾" rung STRADDLE STANDARD COUNTERBALANCED DESIGN
spacing. Ladder capacity is 250 pounds. model A-LIFT-S model A-LIFT-R model A-LIFT-CB
MODEL UNIFORM LOWERED RAISED HEIGHT OVERALL SIZE WEIGHT
NUMBER CAPACITY HEIGHT FORKS DOWN/UP (W x L x H) (POUND)
STANDARD DESIGN (Fixed Straddle Width: 12¾" (I.D.) / 21" (O.D.))
A-LIFT-R� 500 lb. 3½" / 23½" 47" / 67" 24" x 35" x 68¾" 191
5
A-LIFT-R-HP� 400 lb. 3½" / 23½" 97" / 117" 25" x 35" x 67 /16" 203
STRADDLE DESIGN (Adjustable Straddle Width: 21¾" to 36¼" (I.D.) / 29" to 43 /8" (O.D.))
7
1
5
7
7
A-LIFT-S� 500 lb. 1¼" / 21¼" 47 /4" / 68 /8" 43 /8" x 42½" x 67 /16" 200 OPTIONAL
7
7
5
A-LIFT-S-HP� 400 lb. 1¼" / 21¼" 98 /16" / 120" 43 /8" x 42½" x 67 /16" 219 RETRACTABLE
LADDER
11
7
1
A-LIFT-S-EHP� 350 lb. 1¼" / 21¼" 122" / 143 /16" 43 /8" x 42½" x 79 /8" 226 model A-LIFT-LAD
COUNTERBALANCE DESIGN (Adjustable Straddle Width: 21½" to 36½" (I.D.) / 28¼" to 43¼" (O.D.)) (counterweight included)
7
1
7
1
5
A-LIFT-CB� 500 lb. 2" / 21¼" 47 /4" / 68 /8" 43 /4" x 45 /8" x 67 /16" 437
1
7
5
7
A-LIFT-CB-HP� 400 lb. 2" / 21¼" 98 /16" / 120" 43 /4" x 45 /8" x 67 /16" 445
11
1
1
A-LIFT-CB-EHP� 350 lb. 2" / 21¼" 122" / 143 /16" 43 /4" x 46" x 79 /8" 454
OPTIONS
A-LIFT-DK� DECK PLATFORM (20½"W x 24¼"L) (works only when forks are flipped down) 17
A-LIFT-PN� 10" PNEUMATIC REAR WHEELS (cannot use with CB units) 11
A-LIFT-LAD� RETRACTABLE LADDER (A-LIFT-R, A-LIFT-R-HP, A-LIFT-S & A-LIFT-S-HP) 16
A-LIFT-EHP-LAD� RETRACTABLE LADDER (A-LIFT-S-EHP) 17
Hydra Carts model model
HYDRA-2 HYDRA-4
Transport loads in the lowered position and maneuver work materials to an ergonomic
height. Ideal in compact work areas. Safe and easy one person handling of loads up to
1,000 pounds. An efficient way to unload heavy objects from semi trailers. Rugged steel
construction for years of service. Dependable precision built hydraulic system is activated
by easy action foot lever. Additional rollers on the handle make loading into a delivery
truck easy. Steel construction. Approximately 1" of lift per pump. HYDRA-HD has (2)
two swivel casters with brakes. Units come standard with a single wheel brake.
MODEL PLATFORM SERVICE UNIFORM WEIGHT
NUMBER SIZE (W x L) RANGE CAPACITY (POUND)
7
3
HYDRA-2� 20" x 16 /16" 2 /8" to 52" 750 lb. 191
3
HYDRA-4� 20" x 21 /8" 5½" to 52" 750 lb. 220
3
HYDRA-HD� 24" x 21 /8" 4¾" to 52¾" 1,000 lb. 241
HYDRA CART OPTIONS
HYDRA-AF-18 3"W x 18"L FORKS (HYDRA-4 & HYDRA-HD only) 41
HYDRA-H� HAND CRANK WINCH & HOOK (400 lb. capacity) 18
model HYDRA-AF-18 model model HYDRA-H
O.D. of forks 6" to 22" HYDRA-HD
Portable Worksite Lift
Ideal for positioning loads where they are needed. Includes a lifting platform and an overhead
lifting boom for unique applications. Features manual hand crank cable winch with hook.
Portability is easy with 8" x 2" phenolic swivel casters and push handle. Overall size is 36½"
wide, 48½" long, and 90 / 16" high. Unit knocks-down in six pieces - base, legs, and upright.
9
Ideal for storage in tight places and for transportation in the back of a vehicle. Welded steel
construction with painted finish. Uniform capacity is 500 pounds. Distance between front model
5
outriggers is 27 / 8". LIFTER-2
MODEL PLATFORM PLATFORM BOOM BOOM WEIGHT
NUMBER SIZE (W x L) SERVICE RANGE SERVICE RANGE REACH (POUND)
LIFTER-2� 20" x 20" 14¾" to 70" 0" to 80" 25" 388
