158 Steel Manual Carousels
PACKAGING EQUIPMENT SEPARATED TO ILLUSTRATE BEARINGS unloading operations can be done more efficiently; minimizing fatigue and risk of back injury. The

The Manual Carousels rotate materials with the assistance of an operator. Now loading and
carousel may be added to an existing work bench, scissor table, or placed on the floor. Constructed
3
of two (2) pieces of rolled structural angle ( /16"" thick). A series of sealed ball bearings transfer the
load smoothly and evenly to the supporting surface. Four (4) guide rollers keep the rings aligned.
CAROUSEL IS SHOWN WITH RINGS
UNIFORM
WEIGHT
SHIPS
OVERALL
MODEL
OUTER
HEIGHT
DIAMETER
(POUND)
VIA
CAPACITY (LB.)
NUMBER
18"
2,000
UPS
21
2"
CA-18-2�
CA-24-2�
30
24"
UPS
2"
4,000
CA-24-4�
34
30"
2,000
2"
UPS
CA-30-2�
2"
30"
4,000
36
UPS
CA-30-4� 24" 2,000 2" UPS 28
CA-36-2� 36" 2,000 2" UPS 41
CA-36-4� 36" 4,000 2" UPS 45
CA-40-2� 40" 2,000 2" UPS 47
CA-40-4� 40" 4,000 2" UPS 49
CA-40-6� 40" 6,000 2" UPS 51
CA-48-2� 48" 2,000 2" TRUCK 71
HAND OPERATED SPRING LOCKING DETENT CA-48-4� 48" 4,000 2" TRUCK 86
LOCKS CAROUSEL EVERY 90° 48" 6,000 2" TRUCK 97
model CA-HOD CA-48-6�
CA-60-2� 60" 2,000 2" TRUCK 110
CA-60-4� 60" 4,000 2" TRUCK 116
CA-60-6� 60" 6,000 2" TRUCK 128
CA-72-2� 72" 2,000 2" TRUCK 163
CA-72-4� 72" 4,000 2" TRUCK 163
CA-72-6� 72" 6,000 2" TRUCK 169
HAND OPERATED MANUAL BRAKE
LOCKS CAROUSEL IN ANY POSITION CAROUSEL OPTIONS (IN ADDITION TO THE CAROUSEL)
(cannot be used with square top plate) CA-HBK MANUAL BRAKE (FIELD INSTALLED) 3
model CA-HBK CA-HOD HAND OPERATED LOCKING DETENT (FACTORY INSTALLED) 2
CA-FTK FOOT OPERATED LOCKING DETENT (FACTORY INSTALLED) 3
STEEL TOP PLATES FOR CAROUSEL (1/4" THICK)
MODEL NUMBER MODEL NUMBER OVERALL USE WITH WEIGHT
FOOT OPERATED LOCKING DETENT DIAMOND PLATE SMOOTH PLATE STYLE SIZE CAROUSEL DIA. (POUND)
LOCKS CAROUSEL EVERY 90° CA-TP-18-R-TP CA-TP-18-R-SM ROUND 18" DIA. 18" 35
(cannot be used with square top plate)
model CA-FTK CA-TP-24-R-TP CA-TP-24-R-SM ROUND 24" DIA. 24" 52
CA-TP-30-R-TP CA-TP-30-R-SM ROUND 30" DIA. 30" 72
CA-TP-36-R-TP CA-TP-36-R-SM ROUND 36" DIA. 36" 136
CA-TP-40-R-TP CA-TP-40-R-SM ROUND 40" DIA. 40" 160
CA-TP-48-R-TP CA-TP-48-R-SM ROUND 48" DIA. 48" 210
CA-TP-60-R-TP CA-TP-60-R-SM ROUND 60" DIA. 60" 322
CA-TP-72-R-TP CA-TP-72-R-SM ROUND 72" DIA. 72" 445
CA-TP-18-S-TP CA-TP-18-S-SM SQUARE 18"W x 18"L 18" 35
CA-TP-24-S-TP CA-TP-24-S-SM SQUARE 24"W x 24"L 24" 52
CA-TP-30-S-TP CA-TP-30-S-SM SQUARE 30"W x 30"L 30" 72
CA-TP-36-S-TP CA-TP-36-S-SM SQUARE 36"W x 36"L 36" 136
HAND OPERATED SQUARE CA-TP-40-S-TP CA-TP-40-S-SM SQUARE 40"W x 40"L 40" 160
LOCKING DETENT TOP PLATE CA-TP-48-S-TP CA-TP-48-S-SM SQUARE 48"W x 48"L 48" 210
CA-TP-60-S-TP CA-TP-60-S-SM SQUARE 60"W x 60"L 60" 322
CAROUSEL BASE
CA-TP-72-S-TP CA-TP-72-S-SM SQUARE 72"W x 72"L 72" 445
DO NOT EXCEED THE DIAMETER OF CAROUSEL WHEN ORDERING TOP PLATES
TOP PLATE & TOP RING ARE WELDED TOGETHER. CONTACT FACTORY FOR OTHER FASTENING OPTIONS.
ELEVATED BASES FOR CAROUSELS - 12" HIGH New ELEVATED BASES FOR CAROUSELS - 24" HIGH New
(PRICING IS IN ADDITION TO THE COST OF THE CAROUSEL) (PRICING IS IN ADDITION TO THE COST OF THE CAROUSEL)
MODEL OVERALL SIZE CAPACITY WEIGHT MODEL OVERALL SIZE CAPACITY WEIGHT
NUMBER (W x L) UP TO (LB.) (POUND) NUMBER (W x L) UP TO (LB.) (POUND)
CA-BASE-18-12 18"W x 18"L 2,000 195 CA-BASE-18-24 18"W x 18"L 2,000 330
CA-BASE-24-12 24"W x 24"L 4,000 245 CA-BASE-24-24 24"W x 24"L 4,000 380
CA-BASE-30-12 30"W x 30"L 4,000 295 CA-BASE-30-24 30"W x 30"L 4,000 430
CA-BASE-36-12 36"W x 36"L 4,000 345 CA-BASE-36-24 36"W x 36"L 4,000 460
CA-BASE-40-12 40"W x 40"L 6,000 395 CA-BASE-40-24 40"W x 40"L 6,000 510
CA-BASE-48-12 48"W x 48"L 6,000 450 CA-BASE-48-24 48"W x 48"L 6,000 565
CA-BASE-60-12 60"W x 60"L 6,000 530 CA-BASE-60-24 60"W x 60"L 6,000 645
CA-BASE-72-12 72"W x 72"L 6,000 590 CA-BASE-72-24 72"W x 72"L 6,000 705
