182 Portable Steel Hopper with Power Traction Drive 24V DC POWER STANDARD
FORK TRUCK ATTACHMENTS This factory installed option makes portable equipment easy to maneuver with its 240° 572

Reduce worker fatigue and injury with this 1/3 cubic yard Power Traction Drive Hopper.

turning radius, handle grip/throttle, and auto reverse. This state-of-the-art option allows a
single operator to perform tasks safely and ergonomically. Includes built-in electric drive
motor and DC battery with on-board charger. Maximum speed is 3 mph. Hopper and fork
pockets are included. Fork pockets are 7½"W x 2½"H usable on 18" centers. Hopper has a
blue baked-in powder-coated toughness. Must be attached to fork truck when dumping.

MODEL
WEIGHT
OVERALL SIZE
VOLUME
UNIFORM
CAPACITY
(W x L x H)
(POUND)
NUMBER
CUBIC YARDS
HOP-PTD
1,500 lb.
26" x 67 /8" x 45 /8"
1/3
5
5
Open Ended Steel Dumping Hopper
Reduce bending and lifting motions while loading items into a hopper. This hopper will allow
for convenient and orderly loading at ground level with its open front design. Flat items can be
loaded so more can be put into the hopper. Rolls smoothly on 4" x 2" glass filled nylon casters,
the hopper can easily be moved from one location to another. Once the hopper is full or the
user has finished loading, the hopper can be easily dumped with the use of a fork truck.
Must be attached to fork truck when dumping.
MODEL UNIFORM OVERALL SIZE WEIGHT
NUMBER CAPACITY (W x L x H) (POUND)
HOP-OE 2,000 lb. 54½" x 66 /16" x 53 /16" 640
13
5
Steel Chute Hoppers

Unit is designed for use in areas with limited space. Fixed-position hopper features a full-
height front door that opens to dump the hopper contents. Door will automatically close and
lock after contents have been dumped. Front door is opened with a release cable that may be
operated from a safe distance. Units may be moved with assistance from a fork truck. Usable
fork pockets measure 7½"W x 2½"H on 30" centers. Safety restraint is attached for securing
unit to the carriage of the fork truck. Not for use with fine grain or high density materials.
Welded steel construction with blue painted finish. Uniform capacity is 2,000 pounds.
Must be attached to fork truck when dumping.

MODEL VOLUME OVERALL SIZE GAUGE WEIGHT
NUMBER CUBIC YARDS (W x L x H) OF STEEL (POUND)
C-HOP-200 2 60½" x 56 /8" x 67" 7 806
7
C-HOP-300 3 85 /8" x 57¼" x 67" 7 970
5

Triple-Bin Recycling Hopper

This unique Triple-Bin Recycling Hopper is designed for holding different materials. Bins
are painted three different colors; green, red, and blue, and include a manual pull-cable to
dump from the seat of a fork truck. Each bin may be dumped independently and returns
to upright position when lowered to the ground. Includes a safety strap to secure hopper to
forklift. Poly lids are sold separately, see page 181. Hoppers have a baked-in powder-coated
toughness. Each bin holds up to 1/2 cubic yard of material. Maximum total weight capacity
is 2,000 pounds evenly distributed.

MODEL OVERALL SIZE INDIVIDUAL BIN UNIFORM WEIGHT
NUMBER (W x L x H) SIZE (W x L x H) CAPACITY (POUND)
ENVIR-BIN 80 /16" x 57 /16" x 27 /8" 24" x 46 /16" x 23 /16" 2,000 lb. 900
5
1
11
5
5
Shown with optional poly
lids, available separately.
