Fabric Hoppers

These hoppers provide an economical and convenient means for storing and moving dry
bulk commodities. The coated polypropylene has a polyester webbing for extra strength. The
8 oz. white fabric is UV tested. Fold for easy storage when not in use. The four corner straps
provide convenient forklift handling, while the bottom of the unit can be opened for simple
release of products.

MODEL VOLUME UNIFORM BASE SIZE OVERALL WEIGHT FORK TRUCK ATTACHMENTS
NUMBER CUBIC FEET CAPACITY (W x L) HEIGHT (POUND)
FAB-H-45� 40 3,300 lb. 36" x 36" 45" 8
FAB-H-55� 50 3,300 lb. 36" x 36" 55" 7
FAB-H-63� 78 3,300 lb. 36" x 36" 63" 8

Bulk Containers
This rugged container maximizes shipping, handling, and storage efficiencies. These units stack
three high and safely accommodate up to 700-800 LB. of uniform solid, pourable, granular, and
non-regulated material. Molded nesting "lugs" or "ribs" prevent units from jamming together. All
are available in a wide variety of colors and with optional permanent, molded-in or raised graphics
and logos. Caster and custom options available, contact factory. Lid standard.
MODEL VOLUME UNIFORM OVERALL SIZE WEIGHT
NUMBER CUBIC FEET CAPACITY (W x L x H) COLOR (POUND)
MHBC-3244-CB 27.5 700 lb. 45" x 45" x 33" BLUE 95 SHOWN WITH
MHBC-3244-JG 27.5 700 lb. 45" x 45" x 33" GREEN 95 OPTIONAL CASTERS
MHBC-3244-O 27.5 700 lb. 45" x 45" x 33" ORANGE 95
MHBC-3244-R 27.5 700 lb. 45" x 45" x 33" RED 95
MHBC-4444-CB 35 800 lb. 45" x 45" x 45½" BLUE 120
MHBC-4444-JG 35 800 lb. 45" x 45" x 45½" GREEN 120
MHBC-4444-O 35 800 lb. 45" x 45" x 45½" ORANGE 120
MHBC-4444-R 35 800 lb. 45" x 45" x 45½" RED 120
MHBC-3244-5C-CB* 27.5 700 lb. 45" x 45" x 39" BLUE 105
MHBC-3244-5C-JG* 27.5 700 lb. 45" x 45" x 39" GREEN 105
MHBC-3244-5C-O* 27.5 700 lb. 45" x 45" x 39" ORANGE 105
MHBC-3244-5C-R* 27.5 700 lb. 45" x 45" x 39" RED 105
MHBC-4444-5C-CB* 35 800 lb. 45" x 45" x 51½" BLUE 120
MHBC-4444-5C-JG* 35 800 lb. 45" x 45" x 51½" GREEN 120
MHBC-4444-5C-O* 35 800 lb. 45" x 45" x 51½" ORANGE 120
MHBC-4444-5C-R* 35 800 lb. 45" x 45" x 51½" RED 120
* 5" ALL SWIVEL CASTERS INCLUDED

Battery Powered Trash Can Dumper and Container

(1) ONE 12V DC POWER STANDARD
One person with a fork truck can safely and easily dump drums into a hopper. DC
powered operation with on-board battery charger. Raise time is 10 seconds and
lowered time is 8 seconds. Dump height is 55¾". A 2 cubic yard Vestil “D” style
hopper is available separately to collect trash. Custom configurations can be made for
most trash containers.
model T-HOP
MODEL OVERALL SIZE UNIFORM WEIGHT shown with D-200-LD
NUMBER DESCRIPTION (W x L x H) CAPACITY (POUND)
T-HOP DUMPER 38 /16" x 103½" x 60 /16" 400 lb. 732
7
5
D-200-LD� HOPPER 56 /16" x 68 /16" x 51 /16" 2,000 lb. 613
11
5
13
