24 Aluminum Truck Dockboards (Welded Aluminum Curbs)
LOADING DOCK EQUIPMENT heavy fork trucks and loads. The beveled edge is designed for smooth entry and exit.

Aluminum Truck Dockboards are engineered and built to maximize safety while handling
Locking legs prevent movement during loading and unloading operations. Locking legs
are uneven to allow the dockboard to sit canted, while not in use, for easier pickup by fork
trucks. Welded aluminum safety curbs prevent accidental runoffs and provide a visible
driving lane. When using three-wheeled fork trucks order dockboard with capacity at least
four-times the lifting capacity of fork truck. The width of the dockboard should be at least
15 (in.) wider than the load or equipment passing between the curbs. Bend is 11° and 9"
from the edge and the legs are 12" from the edge. Manufactured in compliance with OSHA.

CAPACITY is based upon the heaviest type of equipment used plus the maximum load
to dock. (Numbers listed reference an empty truck.)
carried times the single axle rating of total load. Dynamic loading, driver tendencies,
speed, and frequency of use must be considered. Steel (TS-series) dockboards
54" to 61"
RefRigeRated
recommended for high use docks.
51" to 56"
Heavy tRaileRs
EQUIPMENT
Heavy semi-tRaileRs
48" to 54"
100%

45" to 49"
two-wHeel Hand tRucks SINGLE AXLE RATING OF TOTAL LOAD Use this guide for truck floor heights to determine the Height Differential from the truck bed
ligHt semi-tRaileRs
fouR-wHeel PlatfoRm tRuck - (non-tilt) 50% laRge single Bed 42" to 50"
Pallet tRucks - Hand 75% small single Bed 30"
Pallet tRucks - electRic 66%
PlatfoRm (skid) tRucks - Hand - walkie 75% Use first & second column of chart below to determine length of board.
PlatfoRm (skid) tRucks - electRic - walkie 66% Rise/Run (x 100) = % of Grade.
foRk tRucks - electRic walkie 90%
foRk tRucks - electRic RideR 90%
foRk tRucks - gas RideR 90%
UNIFORM CAPACITY 5,000 LBS. 6,000 LBS. 8,000 LBS. 10,000 LBS.
Size Ht. Difference Ht. Difference Net Wt. Net Wt. Net Wt. Net Wt.
Width-Length 8°/17% 11°/19%
Inches Inches Inches Model Number (Pound) Model Number (Pound) Model Number (Pound) Model Number (Pound)
36 4 5 BTA-05005436 79 BTA-06005436 73 BTA-08005436 112
54 48 5½ 7 BTA-05005448 98 BTA-06005448 109 BTA-08005448 118
60 7 10 BTA-05005460 124 BTA-06005460 134 BTA-08005460 149
30 3 4 BTA-05006030 72 BTA-06006030 81 BTA-08006030 100 BTA-10006030 106
36 4 5 BTA-05006036 82 BTA-06006036 91 BTA-08006036 110 BTA-10006036 123
42 5 6 BTA-05006042 95 BTA-06006042 101 BTA-08006042 114 BTA-10006042 136
48 5½ 7 BTA-05006048 105 BTA-06006048 120 BTA-08006048 126 BTA-10006048 173
60 54 6 8½ BTA-05006054 123 BTA-06006054 132 BTA-08006054 151 BTA-10006054 194
60 7 10 BTA-05006060 133 BTA-06006060 144 BTA-08006060 166 BTA-10006060 197
66 8 11 BTA-05006066 156 BTA-06006066 156 BTA-08006066 172 BTA-10006066 215
72 8½ 12 BTA-05006072 163 BTA-06006072 164 BTA-08006072 191 BTA-10006072 251
78 9 13 BTA-05006078 175 BTA-06006078 179 BTA-08006078 202 BTA-10006078 264
84 10 14 BTA-05006084 197 BTA-06006084 185 BTA-08006084 205 BTA-10006084 285
36 4 5 BTA-05006636 96 BTA-06006636 150 BTA-08006636 112 BTA-10006636 136
66 48 5½ 7 BTA-05006648 116 BTA-06006648 208 BTA-08006648 125 BTA-10006648 208
60 7 10 BTA-05006660 126 BTA-06006660 241 BTA-08006660 214 BTA-10006660 220
30 3 4 BTA-05007230 85 BTA-06007230 81 BTA-08007230 120 BTA-10007230 126
72 36 4 5 BTA-05007236 92 BTA-06007236 91 BTA-08007236 145 BTA-10007236 161
48 5½ 7 BTA-05007248 152 BTA-06007248 130 BTA-08007248 204 BTA-10007248 189
60 7 10 BTA-05007260 195 BTA-06007260 200 BTA-08007260 212 BTA-10007260 247
36 4 5 BTA-05007836 164 BTA-06007836 158 BTA-08007836 188 BTA-10007836 168
78 48 5½ 7 BTA-05007848 196 BTA-06007848 171 BTA-08007848 196 BTA-10007848 215
60 7 10 BTA-05007860 228 BTA-06007860 186 BTA-08007860 206 BTA-10007860 276
36 4 5 BTA-05008436 98 BTA-06008436 209 BTA-08008436 126 BTA-10008436 195
84 48 5½ 7 BTA-05008448 160 BTA-06008448 218 BTA-08008448 156 BTA-10008448 232
60 7 10 BTA-05008460 212 BTA-06008460 235 BTA-08008460 188 BTA-10008460 250
