LOADING DOCK EQUIPMENT STEEL YARD RAMP OPTIONS model YR-HL TOW BAR HITCH TOW BAR POCKET PICK-UP SLOTS NON-REMOVABLE GALVANIZED GUARD RAIL
Options for Yard Ramps
CA Residents see

FORK LIFT
27" PNEUMATIC TIRES
HYDRAULIC HAND PUMP
model YR-TB-P
model YR-TB-H
series YR-GR
STEEL HANDRAIL
model YR-FS
model YR-HDRL
MODEL
WEIGHT
NUMBER
DESCRIPTION
(POUND)
YR-HL
YR-HL-DC*
288
PNEUMATIC TIRE & 12V DC HYDRAULIC LIFT (5 MPH MAX. TOW SPEED) (NOT AVAILABLE ON YRD MODELS)
YR-FS
FORK LIFT PICKUP SLOTS (7½"W X 2½"H USABLE ON 24" CENTERS)
460
YR-TB-H
145
TOW BAR HITCH
YR-TB-P PNEUMATIC TIRE & HAND PUMP HYDRAULIC LIFT (5 MPH MAX. TOW SPEED) (NOT AVAILABLE ON YRD MODELS) 230
35
TOW BAR POCKET (REPLACEMENT)
YR-GR-30 12" HIGH GUARD RAIL OPTION FOR 30 FEET RAMPS (BOTH SIDES) 456
YR-GR-36 12" HIGH GUARD RAIL OPTION FOR 36 FEET RAMPS (BOTH SIDES) 550
YR-HDRL NON-REMOVABLE 42" HIGH STEEL HANDRAIL WITH 21" MIDRAIL (WELDED) 9/FT.
YR-RHDRL REMOVABLE 42" HIGH STEEL HANDRAIL WITH 21" MIDRAIL 9/FT.
YR-RAHDRL REMOVABLE 42" HIGH ALUMINUM HANDRAIL WITH 21" MIDRAIL 3/FT.
YR-DH HOLES IN LIP TO LAG RAMP TO TOP OF DOCK --
*INCLUDES ON-BOARD CHARGER
PNEUMATIC TIRES OPTION TOW BAR POCKET TOW BAR HITCH HAND PUMP
Service Range will be 40" to 66" model AYR-TB-P model AYR-TB-H HYDRAULIC LIFT STANDARD
model AY-PNTR
ALUMINUM YARD RAMP OPTIONS
MODEL WEIGHT
NUMBER DESCRIPTION (POUND)
AYR-HL-DC 12V DC HYDRAULIC LIFT (INCLUDES ON-BOARD CHARGER) 50
AYR-TB-H TOW BAR HITCH 145
AYR-TB-P TOW BAR POCKET (REPLACEMENT) 35
AYR-GR-30 12" HIGH GUARD RAIL OPTION FOR 30 FEET RAMPS 456
AYR-GR-36 12" HIGH GUARD RAIL OPTION FOR 36 FEET RAMPS 550
AY-AHDRL NON-REMOVABLE 42" HIGH ALUMINUM HANDRAIL WITH 21" MIDRAIL (WELDED) (SOLD PER FOOT) 3/FT.
AY-RHDRL REMOVABLE 42" HIGH ALUMINUM HANDRAIL WITH 21" MIDRAIL (SOLD PER FOOT) 18/FT.
AY-RAHDRL REMOVABLE 42" HIGH STEEL HANDRAIL WITH 21" MIDRAIL (SOLD PER FOOT) 18/FT.
AYR-CRB6 6" CURB HEIGHT --
AYR-YEL YELLOW SAFETY CURBS --
AY-PNTR 20½" x 8" PNEUMATIC TIRE OPTION --
AYR-DH HOLES IN LIP TO LAG RAMP TO TOP OF DOCK --
SY-CRB6 6" CURB HEIGHT --
SY-YEL YELLOW SAFETY CURBS --
SY-PNTR 20½" x 8" PNEUMATIC TIRE OPTION --

Steel Railroad Dockboards

• Auto Drop Locks (add 13" to overall width) • Pop-up Fork Lift Loops
• Steel Rectangular Board • Overlap Style Plate (both ends)
• Safety Curbs are 4" High • Tread plate for Better Traction
• Structural Steel Support Beams
DOCK
EDGE Steel Railroad Dockboards have a rectangular-style with a deck that is made of high-strength
raised diamond steel treadplate with structural steel support beams for high strength cross
C
B traffic. Treadplate provides increased traction; overlap-style lip on both dock and rail car ends
gives maximum versatility. Fork truck pop-up loops are built into deck - automatically pop-up
A
when board is set on floor. Automatic drop-locks on both sides of board are designed to keep
the board in place between dock and rail car. Non-returnable. Contact factory for pricing.
NOTE: DIMENSIONS ARE IN INCHES
