Page 291 - Vestil Catalog 112
P. 291
297
Counter-Balanced Drum Lifters (Powered Lift & Power Drive) 12V DC POWER STANDARD
Ideal for confined areas, placing drums in cabinets, loading and unloading drums on/off
pallets and scales. Transport one (1) 30 or one (1) 55 gallon steel, plastic, or fiber drums
with ease. Two (2) 12V DC (lead acid batteries) drive and lift motor handles heavy-duty model S-CB-62-SDC
jobs. Ergonomic handle features easy-to-operate throttle with infinite adjustment of
forward and reverse speeds, lift/lower controls, proprietary safety-enhancing emergency
reverse function, and horn.
MODEL UNIFORM SERVICE WEIGHT
NUMBER DESCRIPTION CAPACITY RANGE (POUND)
S-CB-62-SDC SINGLE GRIP 1,000 lb. 0" TO 62" 1917
S-CB-62-DDC DUAL GRIP 1,000 lb. 0" TO 62" 1967
Deluxe Tilt Back Drum Trucks
Move, tilt, and unload heavy 30 or 55 gallon steel and plastic drums with ease. A foot rest helps DRUM HANDLING EQUIPMENT & SPECIALTY CONTAINERS
in loading and supports a loaded drum truck. Deluxe chime gripper for quick and easy drum
transportation. Assembly required.
DBT-1000 rolls quietly on 10" x 2" mold-on-rubber wheels.
DBT-1000-PN features 15¾" x 4" pneumatic wheels.
MODEL OVERALL SIZE UNIFORM WEIGHT
NUMBER (W x D x H) CAPACITY (POUND)
3
DBT-1000 22½" x 24 /8" x 59" 1,000 lb. 91 PNEUMATIC MOLD-ON-RUBBER
DBT-1000-PN 32" x 27" x 63" 1,000 lb. 81 model DBT-1000-PN model DBT-1000
Barrel/Drum Trucks
Barrel/Drum Trucks handle 30 and 55 gallon steel and fiber drums and barrels that are 24" to
48" high. Adjustable chime hook helps to secure the drum. Wheels measure 12" x 2" or 10" x
2" and are available in rubber-on-steel, poly-on-steel, or polyurethane. Uniform capacity is 800
pounds. DBT-1200 series features a kickstand for holding unit at a tilt. POLY-ON-STEEL
model DBT-1200-P
MODEL OVERALL SIZE WHEEL SIZE WEIGHT
NUMBER (W x D x H) (DIA. x W) WHEEL TYPE (POUND)
DBT-1200 29" x 20¼" x 60" 12" x 2" RUBBER-ON-STEEL 120
DBT-1200-P 29" x 20¼" x 60" 12" x 2" POLY-ON-STEEL 118
DBT-RED 24¼" x 13¾" x 60¼" 10" x 2" POLYURETHANE 48 MOLD-ON-RUBBER POLYURETHANE
model DBT-RED
model DBT-1200
Drum Trucks with Spring Assist
Hand trucks designed for moving 55 gallon steel and plastic drums weighing up to 1,000
pounds. Special design features spring mechanism for easy use. Spring allows for easier tilting of
fully loaded drums. Removable hook bar includes built-in bung nut wrenches. Steel construction
with a baked-in powder-coated toughness, yellow finish. 10" x 2½" wheels standard.
MODEL ACCEPTABLE OVERALL SIZE WEIGHT
NUMBER DRUM TYPE (W x D x H) WHEEL TYPE (POUND)
5
5
DBT-SA-MR STEEL 23½" x 14 /16" x 60 /8" MOR 103
5
5
DBT-SA-PO STEEL 23½" x 14 /16" x 60 /8" POP 110
DBT-P-SA-MR PLASTIC 23½" x 22" x 60 /8" MOR 106 model DBT-P-SA-PO
5
DBT-P-SA-PO PLASTIC 23½" x 22" x 60 /8" POP 110
5
MOR = MOLD-ON-RUBBER / POP = POLY-ON-POLY
Multi-Purpose Drum & Hand Trucks
Multi-purpose unit serves both 30 and 55 gallon steel and plastic drums. Works as a drum
truck, drum cradle, and a hand truck. Extra-long handles give leverage for access to drums
on pallets. Unit lies horizontally for use as a drum cradle to empty drum contents. Steel
nose plate and drum tines are interchangeable. Features large 16" x 4" diameter wheels for
use over rough terrain. Includes built-in bung nut wrench. Ships assembled. Drum is 11⅝"
high when in cradle position.
MODEL OVERALL SIZE UNIFORM WEIGHT
NUMBER (W x L x H) CAPACITY WHEEL TYPE (POUND)
7
DCHT-1 26¾" x 28 /8" x 59 /16" 500 lb. PNEUMATIC 121
13
7
7
DCHT-1-FF 26¾" x 28 /8" x 59 /8" 750 lb. FOAM FILLED 140
