DRUM HANDLING EQUIPMENT & SPECIALTY CONTAINERS
Horizontal Steel Retention Basins

Dispense or store 55 gallon steel drums with these non-flammable heavy-duty Horizontal
Steel Retention Basins. These units are constructed of steel to resist extreme heat
environments. The rugged steel construction provides durability and repairability.
model HSRB-4
Portability is made easy with the built in fork pockets. The built-in horizontal drum
cradles are sloped.
MODEL DRUM OVERALL SIZE UNIFORM WEIGHT
NUMBER CAPACITY (W x L x H) CAPACITY COLOR (POUND)
HSRB-YL-1* 1 27" x 49" x 32" 1,200 lb. YELLOW 195
HSRB-YL-2* 2 49" x 49" x 32" 1,200 lb. YELLOW 325
HSRB-4* 4 61" x 52" x 48" 2,400 lb. BLUE 310
HSRB-1** 1 32" x 52" x 18" 600 lb. BLUE 210
HSRB-2** 2 61" x 52" x 18" 1,200 lb. BLUE 235
*MEETS EPA 40 CPR - 264.175 & UFC 8003.1.3.4
model HSRB-YL-2 **MEETS RCRA, Uniform Fire Code (UFC 8003), EPA 40CPR - 264.175 & UFC 8003.1.3.4

Vertical Steel Retention Basins

Store 55 gallon steel drums in the vertical position with these new non-flammable heavy-duty
Drum Basins. These basins are constructed of steel to resist extreme heat environments. The
rugged steel construction provides durability and repairability. Four way fork entry. Basins are
stackable when empty to provide more space in a warehouse or storage area.

MODEL DRUM OVERALL SIZE UNIFORM WEIGHT
NUMBER CAPACITY (W x L x H) CAPACITY COLOR (POUND)
VSRB-1 1 34" x 34" x 18" 600 lb. BLUE 195
VSRB-YL-2 2 27" x 49" x 14" 1,200 lb. YELLOW 153
VSRB-YL-4 4 49" x 49" x 14" 2,400 lb. YELLOW 211
VSRB-IN-4 4 107" x 34" x 10" 2,400 lb. BLUE 380
VSRB-2* 2 54" x 34" x 14" 1,200 lb. BLUE 205
model VSRB-IN-4
VSRB-4* 4 54" x 50" x 10" 2,400 lb. BLUE 270
*MEETS EPA 40 CPR - 264.175 & UFC 8003.1.3.4

Stackable Transport Pallets with Side Rails
Most spills occur when transporting chemicals. Safely and securely move your chemicals with
our Transport Pallets. Welded all steel construction with a durable finish. Galvanized grating
is easily removable for sump cleanup. 66 gallon sump capacity. Each unit is individually tested
after being welded and before paint for leaks with a low viscous die penetrant test. Four-way
forklift access. Meets EPA 40 CPR-264.175 and UFC 8003.1.3.4 requirements.

MODEL DRUM OVERALL SIZE UNIFORM WEIGHT
NUMBER CAPACITY (W x L x H) CAPACITY COLOR (POUND)
STP-2 2 54" x 34" x 55" 1,200 lb. BLUE 310
STP-4 4 55" x 50" x 54" 2,400 lb. BLUE 385
model STP-4 CA Residents see STP-BAR SECURITY BAR 54" -- -- 4
WARNING A, Pg. 459

Vertical Steel Retention Basins with Separation Walls

These retention basins with splash walls protect and provide additional separation of your
chemicals, while transporting drums. Durability of all steel construction insures years of use in
even the harshest industrial conditions. Arms snap into place on uprights to provide optional
shelf system available for storing smaller drums or other containers. Arms measures 23"W x
18½"D. Enamel blue finish is standard; galvanized is available, contact factory.

MODEL DRUM OVERALL SIZE UNIFORM WEIGHT
NUMBER CAPACITY (D x L x H) CAPACITY COLOR (POUND)
VSRB-WS-2 2 DRUMS 34" x 54" x 55" 1,200 lb. BLUE 320
VSRB-WS-4 4 DRUMS 50" x 55" x 53" 2,400 lb. BLUE 410
model VSRB-WS-4 VSRB-SAU 1 PAIR SHELF ARMS & UPRIGHTS 5
shown with model VSRB-SAU
VSRB-SA 1 PAIR SHELF ARMS 5
