Page 296 - Vestil Catalog 112

302
DRUM HANDLING EQUIPMENT & SPECIALTY CONTAINERS
Intermediate Bulk Containers

Space-saving storage containers are great for multi-trip applications. Designed for storage of
both hazardous and nonhazardous contents. Easy to fill, stack, and load. Steel cage is hot
dipped galvanized material consistent with Food Code requirements for use in non-direct
model IBC-330 food contact environments. Pallet base is made from both steel and plastic. Includes inner
storage tank made from white plastic with UV-blocking additive. Includes 2" butterfly valve
with a durable, synthetic fluorocarbon rubber gasket. Top fill cap is 6" diameter with 2" bung.
Complete unit is UN approved.
Protect IBC spills with our IBC Containment Pallets, series ISCP. All polyethylene
construction makes the unit resistant to chemicals and will not rust. Fork pockets for easy
lifting and positioning. Meets SPCC and EPA Container Storage Regulation 40 CFR 264.175.
model
ISCP-1
MODEL OVERALL SIZE UNIFORM VOLUME WEIGHT
NUMBER (W x L x H) CAPACITY CAPACITY (POUND)
IBC-275 40" x 48" x 46¼" 2,500 lb. 275 GALLON 130
IBC-330 40" x 48" x 53" 3,000 lb. 330 GALLON 140
INTERMEDIATE BULK CRATE SPILL CONTAINMENT PALLETS
MODEL OVERALL SIZE CONTAINMENT UNIFORM FORK POCKETS WEIGHT
NUMBER (W x L x H) CAPACITY CAPACITY (W x H) (POUND)
ISCP-1 62" x 62" x 28" 360 GAL. 8,500 lb. 7¼" x 4" 325
ISCP-2 62" x 124½" x 22" 535 GAL. 8,000 lb. 7¼" x 4¾" 452
ISCS-1* 50 /8" x 53" x 37¼" 400 GAL. 2,500 lb. 7½" x 2½" 1018
7
CA Residents see ISCP-DP OPTIONAL DRIP PAN (19½"W x 16"L x 14½"H) 12
model ISCP-DP WARNING A, Pg. 459
*STEEL CONSTRUCTION

Intermediate Bulk Container Tilting Cart
The Intermediate Bulk Container Tilting Cart is designed of a sturdy steel construction which,
provides a secure tilting of containers for complete draining. To use, simply place the container
on the cart. When the container is in the secure position, start the draining process. As the
fluid flows from the container, the rear of the cart will rise up to 5 degrees creating an angle
for a better release of fluids. The cart rolls on casters for smooth transition from workstation to
workstation.
model IBC-TLT
MODEL OVERALL SIZE LOWERED/RAISED UNIFORM WEIGHT
NUMBER (W x L x H) HEIGHT CAPACITY (POUND)
IBC-TLT 41 /16" x 53 /8" x 35 /16" 12 /4" to 16 /2" 4,400 lb. 261
3
1
3
13
3
Intermediate Bulk Container Heaters

An adjustable wrap around tote tank heater is a great asset to an assortment of container sizes.
With the simple modifiable straps, the heater can be applied easily to an existing unit. An
adjustable thermometer with a built in max temperature reset is also included for both precise
heat allocation and overall safety. To use, easily maneuver the unit around the container and
adjust the straps accordingly until secure.

Model IBC-HEAT-TOP is available to protect integral heat from leaving from unprotected
areas.

MODEL TANK TANK WEIGHT
NUMBER HEIGHT (W x L) VOLTAGE (POUND)
IBC-HEAT-275 42" 40" - 48" 120V 40
IBC-HEAT-330 48" 40" - 48" 120V 58
model IBC-HEAT-330 IBC-HEAT-TOP INSULATED TOP FOR ABOVE MODELS 11
