DRUM HANDLING EQUIPMENT & SPECIALTY CONTAINERS
Four-Wheel Drum Trucks with Tilt-Back Spring Assist
Designed for moving 55 gallon steel or plastic drums. Features a spring mechanism,
which allows for easier tilting of fully-loaded drums. Four-wheel design for easier drum
transportation when tilted. Top loop handle allows for easier control when moving. Drum
is secured to truck with an adjustable height drum hook bar. Removable drum hook bar
includes built-in bung nut wrenches. Capacity is 1,000 pounds. Steel construction with a
baked-in powder-coated toughness.
model DBT-4R-PO MODEL ACCEPTABLE MAIN STABILIZER WEIGHT
NUMBER DRUM TYPE WHEELS CASTERS (POUND)
DBT-4R-MR STEEL (2) 10" RUBBER (2) 6" RIGID RUBBER 110
DBT-4R-PO STEEL (2) 10" POLY (2) 6" RIGID POLY 109
DBT-P-4R-MR PLASTIC (2) 10" RUBBER (2) 6" RIGID RUBBER 109
DBT-P-4R-PO PLASTIC (2) 10" POLY (2) 6" RIGID POLY 109
DBT-4RS-MR STEEL (2) 10" RUBBER (2) 3" SWIVEL POLY 111
DBT-4RS-PO STEEL (2) 10" POLY (2) 3" SWIVEL POLY 111
DBT-P-4RS-MR PLASTIC (2) 10" RUBBER (2) 3" SWIVEL POLY 110
DBT-P-4RS-PO PLASTIC (2) 10" POLY (2) 3" SWIVEL POLY 110
Multi-Purpose Drum Trucks/Cradles
One of the most versatile drum trucks in the industry. This innovative product allows the
operator to easily tip back the truck in order to transport drums ergonomically on four (4)wheels.
Unit doubles as a drum cradle for storage and dispensing all in one. Top angle is 3° when used
as a Drum Cradle. This unique design also allows the operator to place drums and retrieve off
of a pallet. Accommodates 55 gallon steel, plastic, or fiber drums. Rolls smoothly on two (2)
10" x 2½" (wheel types see below), two (2) 6" x 2" poly-on-poly wheels, and two (2) 3" x 1¼"
model RDBT-MR
poly-on-poly swivel casters. Standard with a wheeled undercarriage that positions the drum
horizontally for drainage or storage. The drain height is 12 /16" high in the cradle position. An
13
integral self-storing bung wrench is standard. This attractive feature not only opens numerous
drums, but helps to keep the drum snug on the truck. Baked-in powder-coated toughness.
Optional drip pan with brackets available.
MODEL OVERALL SIZE UNIFORM WEIGHT
NUMBER (W x L x H) CAPACITY WHEEL TYPE (POUND)
5
RDBT-MR 23½" x 20 /16" x 60 /8" 1,000 lb. MOLD-ON-RUBBER 140
1
RDBT-SS 23½" x 20 /16" x 60 /8" 1,000 lb. SEMI-STEEL 158
5
1
1
5
RDBT-PO 23½" x 20 /16" x 60 /8" 1,000 lb. POLY-ON-POLY 148
model RDBT-PO
RDBT-PAN OPTIONAL DRIP PAN (8¼"W x 11"L x 4"H) 3
Stainless Steel Drum Trucks
model DBT-SS, Tilt and lower drums to a horizontal position for dispensing. Grips all types
of steel 30, 55, & 85 gallon drums and most rimmed plastic and fiber drums. Robust, non-
corrosive design - 304 all stainless steel construction. Adjustable chime hook helps to secure the
drum. Kickstand for holding the unit in stand-up position. 4-wheel design offers exceptional
maneuverability through tight areas. 4½" ground clearance with four (4) 8" x 2" nylon wheels.
model DBT-SS-DLX, Easily, efficiently, and safely lift, move, and maneuver a wide range of
steel and plastic drums. Automatic grip can be adjusted manually up and down to suit different
model DBT-SS model DBT-SS-DLX heights. Robust design - 304 all stainless steel construction. 50% less input force is required to
lift a 1,000 lb drum compared to standard drum trucks. To operate, simply push the truck to
drum and attach the automatic grip to the drum rim. Rolls simply and smoothly on two (2) 8"
New x 2" nylon wheels.
MODEL ACCEPTABLE OVERALL SIZE UNIFORM WEIGHT
NUMBER DRUM TYPE (W x D x H) CAPACITY (POUND)
3
DBT-SS STEEL, PLASTIC, FIBER 22¼" x 51 /16" x 37½" 1000 lb. 70
1
1
DBT-SS-DLX STEEL & PLASTIC 31 /8" x 20" x 55 /8" 1000 lb. 95
