190 Hoisting Hooks
FORK TRUCK ATTACHMENTS DOUBLE FORK SINGLE FORK Hoisting Hook does not require the assistance of special tools. Secured to the fork truck by means

Convert your fork truck into a hook with anchor in a matter of seconds. The easy to attach
of a 48" long safety restraint and screw clamps. Available in single or double fork design. Units are
zinc plated. Hook with shackle included.
Model S-FORK-4-AT, Auto-Tension Hoisting Hook, offers a unique design and adds tension as
series S-FORK
weight is added. Hook with shackle included. Secured to the fork truck by means of a 48" long
safety restraint and tine lock, this unit has a yellow baked-in powder-coated toughness.
series D-FORK
USABLE FORK
WEIGHT
DESCRIPTION
UNIFORM
MODEL
(POUND)
HOOK TYPE
CAPACITY
NUMBER
POCKET SIZE (W x H)
6" x 2¼"
SINGLE FORK/RIGID
4,000 lb.
S-FORK-4/6-RL�
S-FORK-4/6-SL�
SINGLE FORK/SWIVEL
6" x 2¼"
4,000 lb.
15
SINGLE FORK
DOUBLE FORK/RIGID
D-FORK-4-RL�
4,000 lb.
7¼" x 2½"
31
AUTO-TENSION
7¼" x 2½"
4,000 lb.
31
D-FORK-4-SL�
model S-FORK-4-AT
53
5
DOUBLE FORK/SWIVEL
D-FORK-10-SL� DOUBLE FORK/SWIVEL 6 /16" x 3½" 10,000 lb. 15
S-FORK-4-AT SWIVEL, SINGLE AUTO-TENSION 5½" x 1 /2" 4,000 lb. 24
1
Forklift Lifting Beam
A Forklift Lifting Beam is the perfect asset for maneuvering and transferring heavy objects. The
LIFTING BEAM centrally located shackle between two fork pockets allow the user to safely attach to the unit and
model FLB-D-10
transport to the desired location. Hooks are also attached to the outside of the unit for a more secure
lifting experience. The strong steel construction with a bright finish enables high visibility from both
near and far. Secure to the fork truck by means of a 48" long safety restraint and screw clamps.
WEIGHT
USABLE FORK
MODEL
New NUMBER OVERALL SIZE POCKET SIZE (W x H) UNIFORM (POUND)
CAPACITY
(W x L x H)
FLB-D-10 4¾" x 40" x 15" 7" x 2½" (13" centers) 10,000 lb. 112
Hook Plates
Hook Plates enable any fork truck to safely lift a load using chains, cables, or slings. Features slanted
fork openings measuring 6½" wide by 1¾" high to prevent the hook plate from being used upside
down. A hook with anchor shackle is included. A safety restraint secures the unit to the fork truck.
MODEL HOOK HEIGHT OVERALL UNIFORM WEIGHT
NUMBER TYPE W/O HOOK WIDTH CAPACITY (POUND)
HOOK PLATE LM-HP4-S� SWIVEL 6" 24" 4,000 lb. 23
model LM-HP4-R LM-HP4-R� RIGID 6" 24" 4,000 lb. 23
LM-HP6-S� SWIVEL 6" 24" 6,000 lb. 25
Fork Truck Bases with Optional Tow Balls & Pintle Hook
Convert your fork truck into a tow truck for moving trailers and other portable equipment.
Simple design slides onto forks and secures into place with pin style tine locks and a safety
restraint. Welded steel construction with blue baked-in powder-coated toughness. 5"W x
2"H usable fork pockets. Optional pintle hook, tow balls, lifting hooks and hitch (see below)
available. Bolt on design. Never exceed the 4,000 lb. capacity of the hook base. An attachment does not
increase the total capacity of the unit.
FORK LENGTH TO UNIFORM WEIGHT
MODEL NUMBER DESCRIPTION LENGTH CENTER OF BALL CAPACITY (POUND)
HOOK-BASE-32� FORK BASE 36" 32 /8" 4,000 lb. 139
3
FORK TRUCK BASE
3
model HOOK-BASE-38 HOOK-BASE-38� FORK BASE 42" 38 /8" 4,000 lb. 162
3
HOOK-BASE-44� FORK BASE 48" 44 /8" 4,000 lb. 166
ABOVE MODELS WORK WITH BALL-178, BALL-200, BALL-2516, HOOK-S-4, HOOK-R-4, PINTLE, HITCH-3B
MODEL BALL SHANK UNIFORM WEIGHT
NUMBER DESCRIPTION DIAMETER DIAMETER CAPACITY (POUND)
7
BALL-178� TOW BALL 1 /8" 1" 2,000 lb. 3
BALL-200� TOW BALL 2" 1" 5,000 lb. 3
5
BALL-2516� TOW BALL 2 /16" 1" 5,000 lb. 4
PINTLE HOOK TOW BALLS MODEL JAW UNIFORM TONGUE UNIFORM TOW WEIGHT
model PINTLE series BALL NUMBER DESCRIPTION OPENING CAPACITY CAPACITY (POUND)
PINTLE PINTLE HOOK 1¾" 2,000 lb. 10,000 lb. 11
